Malanite

Cu1+(Ir3+Pt4+)S4
IMA status
  • Approved
IMA symbol
Mla
Discovered
1974
IMA approved
1995
Also known as
  • IMA1995-003
  • Malaniet

Where it forms, where it's found

Geological setting

peridotite-type platinum ores

Type locality
Unnamed Ni-Cu deposit
  1. Malan river valley
  2. Zunhua Co.
  3. Tangshan
  4. Hebei
  5. China
39recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Steel grey
Streak
Black
Tenacity
brittle
Cleavage
Imperfect/Fair

(111), may be observed.

Density
7.46 g/cm³

Optical

Optical type
Isotropic
Optical colour
bright white with a faint brown to green tint
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Cell parameters
a = 9.925(15) Å
Z
8
Type-locality form

Crystals are octahedral or dodecahedral, to 0.2 mm; massive

Comment

Space Group: F d3m

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
78PtPlatinumPlatinum1195.084195.084
33.69%
77IrIridiumIridium1192.217192.217
33.19%
16SSulfurSulfur432.060128.240
22.15%
29CuCopperCopper163.54663.546
10.97%
Total579.087100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ni
  • Co
  • Fe
  • Pd

Synonyms

  • IMA1995-003
  • Malaniet

In other languages

German
IMA 1995-003 · Malanit
Italian
Malanite

Classification

Strunz
10th ed.

2.DA.05

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DAM:S = 3:4Group
  • 2.DA.05MalaniteSpecies
Dana
8th ed.

02.10.01.17

  • 02SulfidesClass
  • 02.10AmBnXp, with (m+n):p = 3:4Type
  • 02.10.01Linnaeite Group (Isometric: Fd3m)Group
  • 02.10.01.17MalaniteSpecies
CIM

3.12.47

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.12Sulphides etc. of the platinum metalsGroup
  • 3.12.47MalaniteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. New Minerals 1995-1999, 149.
  2. 1974Yu Zuxiang, Lin Shujen, Chao Pao, Fang Chingsung, and Huang Chishun (1974) A preliminary study of some new minerals of the platinum-group and another associated new one in a platinum-bearing intrusion in a region of China. Acta Geologica Sinica: 48(2): 202-218 (in Chinese with English abstract).
  3. 1976Fleischer, Michael, Pabst, Adolf, Mandarino, Joseph A., Chao, George Y., Cabri, Louis, J. (1976) New Mineral Names. American Mineralogist, 61 (1-2) 174-186
  4. 1978Peng, Z., Chang, C., Ximen, L. (1978): Discussion on published articles in the research of new minerals of the platinum-group discovered in China in recent years. Acta Geologica Sinica, 4, 326-336.
  5. 1980Fleischer, Michael, Cabri, Louis J., Pabst, Adolf (1980) New Mineral Names. American Mineralogist, 65 (3-4) 406-408
