Carrollite

CuCo2S4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cli
Also known as
  • Carrolit
  • Carrolite
  • Carrolliet
  • +5 more

Where it forms, where it's found

Geological setting

In veins of chalcopyrite in schist.

In hydrothermal vein deposits

Type locality
Patapsco Mine (Finksburg Mine
  1. Orchard Mine)
  2. Patapsco Mines
  3. Finksburg
  4. Carroll County
  5. Maryland
  6. USA

39.4894°, -76.8775°

187recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Bright silver color

Rarely tarnishes to copper red or violet gray

Streak
Gray black
Tenacity
very brittle
Cleavage
None Observed
Fracture
Irregular/Uneven · Conchoidal · Sub-Conchoidal
Density
4.5 g/cm³

Optical

Pleochroism
Non-pleochroic
Tropism
Isotropic
Reflectance R%
(41.4) 400, (41.5) 420, (41.6) 440, (41.8) 460, (42.0) 480, (42.3) 500, (42.6) 520, (42.9) 540, (43.1) 560, (43.3) 580, (43.5) 600, (43.9) 620, (44.3) 640, (44.7) 660, (45.0) 680, (45.3) 700
UV response
Not fluorescent
Reflected-light panel
43.1 %isotropic · single curve
Specimen sRGB 235, 162, 88
White reference100 % reflector under same lamp

Crystallography

Crystal system
Isometric
Space group
Fd-3m
Cell parameters
a = 9.458 Å
Z
8
Morphology

Octahedral and cubic crystals, massive, granular, compact

Twinning

(111) polysynthetic

Parting
poor on (001)
Type-locality form

Crystalline, homogenous material, but no distinct crystals.

Comment

JCPDS 98-003-1107

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
16SSulfurSulfur432.060128.240
41.42%
27CoCobaltCobalt258.933117.866
38.06%
29CuCopperCopper163.54663.546
20.52%
Total309.652100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ni

Synonyms

  • Carrolit
  • Carrolite
  • Carrolliet
  • Corrolit
  • Corrolita
  • Corrolite
  • Sychnodymit
  • Sychnodymite

In other languages

French
Carrolite · Carrollite · Corrolite · Sychnodymite
German
Carrollit
Spanish
Carrolita · Carrollita
Italian
Carrollite
Chinese
硫銅鈷礦

Classification

Strunz
10th ed.

2.DA.05

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DAM:S = 3:4Group
  • 2.DA.05CarrolliteSpecies
Dana
8th ed.

02.10.01.02

  • 02SulfidesClass
  • 02.10AmBnXp, with (m+n):p = 3:4Type
  • 02.10.01Linnaeite Group (Isometric: Fd3m)Group
  • 02.10.01.02CarrolliteSpecies
CIM

3.10.18

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.10Sulphides etc. of CoGroup
  • 3.10.18CarrolliteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Gauthier, Gilbert, King, Van, and Morgan, Robert. Carrollite from Kamoya South II Mine, Katanga, Democratic Republic of the Congo. Mineralogical Record, (in press).
  2. 1852Faber, W.L. (1852) On Carrollite, a new Cobalt Mineral, American Journal of Science, second series, 13, 418-419.
  3. 1891Laspeyres, H. (1891): Sychnodymit, ein neues Kobalterz von der Grube Kohlenbach bei Eiserfeld unweit Siegen. Zeitschrift für Kristallographie: 19: 17-21.
  4. 1928De Jong, W.F., Hoog, A. (1928) Carrollite (sychnodymite). Zeitschrift für Kristallographie, 66, 168-171.
  5. 1969Ramdohr, Paul (1969) The Ore Minerals and their Intergrowths. Pergamon Press, Oxford. 1174pp. doi:10.1016/c2013-0-10027-xDOI: 10.1016/c2013-0-10027-x
