Manganoeudialyte

Na14Ca6Mn3Zr3[Si26O72(OH)2](H2O,Cl,O,OH)6
IMA status
  • Approved
IMA symbol
Meud
IMA approved
2009
Also known as
  • IMA2009-039

Where it forms, where it's found

Geological setting

In a khibinite.

Type locality
Pedra Balão outcrops
  1. Poços de Caldas
  2. Minas Gerais
  3. Brazil

-21.7611°, -46.5564°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pink to purple
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.890 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.603 – 1.608
Surface relief
Moderate
Principal indices
nω 1.603 · nε 1.608
Pleochroism
Non-pleochroic
UV response
Shows no fluorescence under both long- and short-wave ultraviolet light.
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R3m
Cell parameters
a = 14.253(1) Å · c = 30.079(4) Å
Unit cell volume
5292 ų
Z
3
Parting
Not observed
Type-locality form

In cm-sized patches interstitial to the main minerals of the rock.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen9215.9991471.908
42.84%
14SiSiliconSilicon2628.085730.210
21.25%
11NaSodiumSodium1422.990321.860
9.37%
40ZrZirconiumZirconium391.224273.672
7.96%
20CaCalciumCalcium640.078240.468
7.00%
17ClChlorineChlorine635.450212.700
6.19%
25MnManganeseManganese354.938164.814
4.80%
1HHydrogenHydrogen201.00820.160
0.59%
Total3435.792100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2009-039

In other languages

German
IMA 2009-039 · Manganoeudialyt
Italian
manganoeudialyte

Classification

Strunz
10th ed.

9.CO.10

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CO[Si9O27]18- 9-membered ringsGroup
  • 9.CO.10ManganoeudialyteSpecies
Dana
8th ed.

64.01.01.04

  • 64Cyclosilicates Rings with Other Anions and Insular Silicate GroupsClass
  • 64.01Rings with Other Anions and Insular Silicate Groups with mixed ring typesType
  • 64.01.01Eudialyte GroupGroup
  • 64.01.01.04ManganoeudialyteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2003Johnsen, O., Ferraris, G., Gault, R. A., Grice, J. D., Kampf, A. R., Pekov, I. V. (2003) The nomenclature of eudialyte-group minerals. The Canadian Mineralogist, 41 (3) 785-794 doi:10.2113/gscanmin.41.3.785 DOI: 10.2113/gscanmin.41.3.785
  2. 2010Atencio, D., Nomura, S.F., Chukanov, N.V., Rastsvetaeva, R.K., Coutinho, J.M.V., Karipidis, T.K. (2010) Manganoeudialyte, a new mineral from Poços de Caldas, Minas Gerais, Brazil. 20th General Meeting of the IMA (IMA2010), Budapest, Hungary, August 21-27, CD of Abstracts: 492.
  3. 2010Nomura, S.F., Atencio, D., Chukanov, N.V., Rastsvetaeva, R.K., Cutinho, J.M.V., Karipidis, T.K. (2010) Manganoeudialyte, a new mineral from Poços de Caldas, Minas Gerais, Brazil. Zapiski Rossiiskogo Mineralogicheskogo Obshchestva: 139(4): 35-47.
  4. 2010Horváth, L., Horváth, E. (2010) Recent (2009-2010) additions to the minerals of MSH. Micronews: 44(3): 16-23.
  5. 2014(2014) Manganoeudialyte. Handbook of Mineralogy. Mineralogical Society of America
