Eudialyte

Na15Ca6Fe3Zr3Si(Si25O73)(O,OH,H2O)3(Cl,OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Eud
Discovered
1819
Also known as
  • Almandine spar
  • Eudalit
  • Eudalita
  • +8 more

Where it forms, where it's found

Geological setting

Nepheline syenites, alkalic granites.

Type locality
Kangerluarsuk Fjord
  1. Ilímaussaq complex
  2. Kujalleq
  3. Greenland

60.8759°, -45.8737°

199recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous.
Transparency
Translucent
Colour
Variable: Carmine-red · orange-red · orange · pink · cherry-red · brownish-red · yellowish-brown · brown · yellow · violet · green
Streak
White to pale pink
Tenacity
brittle
Cleavage
Perfect

Distinct on (0001), imperfect on (1010) and (1014) (1120).

Fracture
Irregular/Uneven
Density
2.74 g/cm³

Optical

Optical type
Uniaxial (+/-)
Refractive index
1.606 – 1.613
Surface relief
Moderate
Principal indices
nω 1.606 – 1.61 · nε 1.61 – 1.613
Pleochroism
Weak

O= colorless, pale yellow, pink E= pink to colorless

Michel-Lévy diagramhighlighted lineδ = 0.0035
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]35 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation35 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 14.31 Å · c = 30.15 Å
Z
3
Morphology

short rhombohedral to long prismatic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen8415.9991343.916
42.23%
14SiSiliconSilicon2628.085730.210
22.94%
11NaSodiumSodium1522.990344.850
10.83%
40ZrZirconiumZirconium391.224273.672
8.60%
20CaCalciumCalcium640.078240.468
7.56%
26FeIronIron355.845167.535
5.26%
17ClChlorineChlorine235.45070.900
2.23%
1HHydrogenHydrogen111.00811.088
0.35%
Total3182.639100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • K
  • Mg
  • Sr
  • TR
  • Ti
  • Nb
  • Al
  • F
  • P
  • S

Synonyms

  • Almandine spar
  • Eudalit
  • Eudalita
  • Eudalite
  • Eudyalit
  • Eudyalita
  • Eudyalite
  • Grönländischer Hyazinth
  • Mesodyalit
  • Mesodyalite
  • Saami Blood

In other languages

French
Eudialyte
German
Eudialyt
Spanish
Eudialita
Italian
Eudialite · Eudialyte
Japanese
ユージアル石 · ユーディアライト
Chinese
异性石
Russian
Эвдиалит
Arabic
إيودياليت

Classification

Strunz
10th ed.

9.CO.10

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CO[Si9O27]18- 9-membered ringsGroup
  • 9.CO.10EudialyteSpecies
Dana
8th ed.

64.01.01.01

  • 64Cyclosilicates Rings with Other Anions and Insular Silicate GroupsClass
  • 64.01Rings with Other Anions and Insular Silicate Groups with mixed ring typesType
  • 64.01.01Eudialyte GroupGroup
  • 64.01.01.01EudialyteSpecies
CIM

17.3.6

  • 17Silicates Containing other AnionsClass
  • 17.3Silicates with chloride (including aluminosilicates)Group
  • 17.3.6EudialyteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1810Klaproth, M. H. (1810) CXCIII. Chemische Untersuchung des rothen Granats aus Grönland. In Beiträge zur chemischen Kenntniss der Mineralkörper Vol. 5. Rottmann. p.131-137.
  2. 1972Edgar, A.D., Blackburn, C.E. (1972) Eudialyte from the Kipawa Lake area, Temiscamingue CO., Quebec. The Canadian Mineralogist, 11, 554-559.
  3. 1997Johnsen, O.; Gault, R. A. (1997) Chemical variation in eudialyte. Neues Jahrbuch für Mineralogie - Abhandlungen, 171 (3). 215-237 doi:10.1127/njma/171/1997/215DOI: 10.1127/njma/171/1997/215
  4. 1997Johnsen, O., Petersen, O. V., Gault, R. A. (1997) Optical data on minerals of the eudialyte group: Discussion of the eucolite-mesodialyte-eudialyte terminology. Neues Jahrbuch für Mineralogie - Monatshefte, 1997 (8) 371-383 doi:10.1127/njmm/1997/1997/371DOI: 10.1127/njmm/1997/1997/371
  5. 1998Johnsen, O. and Grice, J.D. (1998) Crystal chemical characteristics of the eudialyte group. Program with Abstracts, International Mineralogical Association Meeting, Toronto, A108.
