Mcguinnessite

CuMg(CO3)(OH)2
IMA status
  • Approved
IMA symbol
Mgu
Also known as
  • IMA1977-027
  • Mcguinnessiet

Where it forms, where it's found

Geological setting

Rodingitized metagabbro dikes in a serpentinized peridotite

Type locality
Copper King Mine
  1. Red Mountain
  2. Red Mountain Mining District
  3. Mendocino County
  4. California
  5. USA

39.0754°, -123.1022°

43recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Light blue-green · Cu-rich cores slightly darker blue · Mg-rich rims very pale blue-green to nearly white
Streak
White
Tenacity
brittle
Cleavage

Fracture: Even

Density
3.02 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.596 – 1.732
Surface relief
High
Principal indices
nα 1.596 – 1.602 · nβ 1.724 – 1.73 · nγ 1.724 – 1.732
Pleochroism
Weak

Z,Y (light bluish green); X (very pale green)

Dispersion
r < v weak
UV response
None observed
Michel-Lévy diagramhighlighted lineδ = 0.1290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1290 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1290 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 9.398(2) Å · b = 12.011(2) Å · c = 3.379(2) Å
Cell angles
β = 93.28(5) °
Ratio a:b:c
1 : 1.278 : 0.360
Z
4
Type-locality form

Spherules on joint and vein surfaces.

Comment

May be triclinic. Space Group: P2/a or P21/a

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
43.98%
29CuCopperCopper163.54663.546
34.94%
12MgMagnesiumMagnesium124.30524.305
13.36%
6CCarbonCarbon112.01112.011
6.61%
1HHydrogenHydrogen21.0082.016
1.11%
Total181.873100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1977-027
  • Mcguinnessiet

In other languages

German
IMA 1977-027 · Mcguinnessit
Spanish
Mcguinnessita
Italian
Mcguinnessite

Classification

Strunz
10th ed.

5.BA.10

  • 5CarbonatesClass
  • 5.BCarbonates with additional anions, without H2ODivision
  • 5.BAWith Cu, Co, Ni, Zn, Mg, MnGroup
  • 5.BA.10McguinnessiteSpecies
Dana
8th ed.

16a.03.01.04

  • 16aAnhydrous Carbonates Containing Hydroxyl or HalogenClass
  • 16a.03(AB)2(XO3)ZqType
  • 16a.03.01Rosasite GroupGroup
  • 16a.03.01.04McguinnessiteSpecies
CIM

11.3.11

  • 11CarbonatesClass
  • 11.3Carbonates of MgGroup
  • 11.3.11McguinnessiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1981Fleischer, Michael, Cabri, Louis J. (1981) New Mineral Names. American Mineralogist, 66 (11-12) 1274-1280
  2. 1981Erd, Richard C., Cesbron, Fabien P., Goff, Fraser, Clark, Joan R. (1981) Mcguinnessite, a New Carbonate from California. The Mineralogical Record, 12 (3) 143-147
  3. 1981Schmetzer, K., Tremmel, G. (1981) Mcguinnessit (Mg,Cu)2CO3(OH)2 aus Bou Azzer, Marokko - ein neuer Fundpunkt. Neues Jahrbuch für Mineralogie - Monatshefte, 1981. 443-451
  4. 1984Read, A. J. (1984) Mcguinnessite from New Zealand; a new occurrence. Mineralogical Magazine, 48 (348) 457-459 doi:10.1180/minmag.1984.048.348.18 DOI: 10.1180/minmag.1984.048.348.18
  5. 2004Perchiazzi, N. (2004) EPDIC European Powder diffraction conference Praha 2004: 11: 76.
