Metacinnabar

HgS
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mcin
Also known as
  • Aethiops Mineral
  • Metacinnabarite

Where it forms, where it's found

Type locality
Redington Mine (Boston Mine
  1. Knoxville Mine
  2. Excellsior Mine)
  3. Knoxville
  4. Knoxville Mining District
  5. Napa County
  6. California
  7. USA

38.8253°, -122.3389°

250recorded occurrences
Source · OpenStreetMap

Varieties

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Dark red to black
Streak
black
Tenacity
brittle
Fracture
Sub-Conchoidal
Density
7.65 g/cm³

Optical

Optical type
Isotropic
Pleochroism
Weak
Optical colour
Mid grey
Anisotropism
very weak, rarely
Internal reflections
Red
Tropism
Isotropic
Reflectance R%
(28.4) 400, (27.6) 420, (26.8) 440, (26.3) 460, (25.9) 480, (25.6) 500, (25.4) 520, (25.2) 540, (25.1) 560, (25.0) 580, (24.9) 600, (24.9) 620, (24.8) 640, (24.7) 660, (24.7) 680, (24.7) 700
Reflected-light panel
25.6 %isotropic · single curve
Specimen sRGB 182, 127, 72
White reference100 % reflector under same lamp
Anisotropism
very weak, rarely
Reflected colour
Mid grey
Internal reflections
Red

Crystallography

Crystal system
Isometric
Space group
#208
Cell parameters
a = 5.8717(5) Å
Z
4
Morphology

Massive, rarely as small <1mm tetrahedral crystals

Twinning

Common on (111), forming lamellae in polished section.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury1200.592200.592
86.22%
16SSulfurSulfur132.06032.060
13.78%
Total232.652100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Aethiops Mineral
  • Metacinnabarite

In other languages

French
Métacinabre · Metacinnabar · Metacinnabarite
German
Metacinnabarit
Spanish
Leviglianita · Metacinabarita · Metacinabrio
Italian
Metacinabro
Chinese
黑辰砂

Classification

Strunz
10th ed.

2.CB.05a

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CBWith Zn, Fe, Cu, Ag, etc.Group
  • 2.CB.05aMetacinnabarSpecies
Dana
8th ed.

02.08.02.03

  • 02SulfidesClass
  • 02.08AmXp, with m:p = 1:1Type
  • 02.08.02Sphalerite Group (Isometric: F4-3m)Group
  • 02.08.02.03MetacinnabarSpecies
CIM

3.5.3

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.5Sulphides etc. of Hg and TlGroup
  • 3.5.3MetacinnabarSpecies

Group, growth & confusion

In the same group
8 members
Often grow together
1 mineral
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1870Moore, G.E. (1870) Ueber das Vorkommen des amorphen Quecksilbersulfids in der Natur. Journal für Praktische Chemie: 110: 319-329.
  2. 1873Durand, F.E. (1873) Notes on the crystallization of metacinnabarite. Proceedings of the California Academy of Sciences, ser. 1, 4(1): 219–220, figs. 1–2.
  3. 1885Penfield, S.L. (1885) Crystallized tiemannite and metacinnabarite. American Journal of Science: 29: 449-454.
  4. 1892Penfield, S.L. (1892) Notes on the crystallography of metacinnabarite. American Journal of Science, 3rd. series: 44: 383.
  5. 1892Schrauf, A. (1892) Ueber Metacinnaberit von Idria und dessen Paragenesis. Jahrbuch der Kaiserlich-Königlichen Geologischen Reichsanstalt: 41: 349-400.
