Metarauchite

Ni(UO2)2(AsO4)2 · 8H2O
IMA status
  • Approved
IMA symbol
Mrau
IMA approved
2008
Also known as
  • IMA2008-050
  • Metarauchiet
  • UM1997-18-AsO:HNiU

Where it forms, where it's found

Geological setting

Oxidation of Ag + As + Co + Ni ± Bi and U mineralization

Type locality
Eduard Mine
  1. Jáchymov
  2. Karlovy Vary District
  3. Karlovy Vary Region
  4. Czech Republic

50.3827°, 12.8933°

7recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Yellow to light greenish yellow
Streak
light green to pale yellow strea
Tenacity
brittle
Cleavage
Perfect

(011)

Fracture
Irregular/Uneven
Density
3.81 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 52°
Refractive index
1.625 – 1.649
Surface relief
Moderate
Principal indices
nα 1.625 · nβ 1.649 · nγ 1.649
Pleochroism
Non-pleochroic
UV response
none
Notes

with β = 1.646, γ = 1.651 and to 23° with β = 1.649, γ = 1.650

Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.194(2) Å · b = 9.759(5) Å · c = 13.231(7) Å
Cell angles
α = 75.53(3) ° · β = 84.01(3) ° · γ = 81.59(3) °
Ratio a:b:c
1 : 1.357 : 1.839
Z
2
Twinning

multiply twinned along (011)

Type-locality form

thick tabular crystals with a prevalence of the pinacoid (011)

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
46.64%
8OOxygenOxygen2015.999319.980
31.35%
33AsArsenicArsenic274.922149.844
14.68%
28NiNickelNickel158.69358.693
5.75%
1HHydrogenHydrogen161.00816.128
1.58%
Total1020.703100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2008-050
  • Metarauchiet
  • UM1997-18-AsO:HNiU

In other languages

German
IMA 2008-050 · Metarauchit
Italian
metarauchite

Classification

Strunz
10th ed.

8.EB.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.05MetarauchiteSpecies
Dana
8th ed.

40.2a.31.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.31— unnamed intermediate level —Group
  • 40.2a.31.01MetarauchiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2008Williams, P.A., Hatert, F., Pasero, M. (2008) New minerals approved in 2008. in International Mineralogical Association: 1-13.
  2. 2010Plášil, J., Sejkora, J., Čejka, J., Novák, M., Viñals, J., Ondruš, P., Veselovský, F., Škácha, P., Jehlička, J., Goliáš, V., Hluošek, J. (2010) Metarauchite, Ni(UO2)2(AsO4)2·8H2O, from Jáchymov, Czech Republic and Schneeberg, Germany: a new member of the autunite group. The Canadian Mineralogist, 48 (2) 335-350 doi:10.3749/canmin.48.2.335 DOI: 10.3749/canmin.48.2.335
  3. 2011Stark, Jörg (2011) Die weltweit zweite Fundstelle für Metarauchit. Eine interessante Paragenese sekundärer Uranmineralien in Schneeberg [The world's second metarauchite locality. A paragenesis of secondary uranium minerals in Schneeberg]. Mineralien-Welt, 22 (1). 32-40
  4. 2011Poirier, G., Tait, K. T., Rowe, R. (2011) New Mineral Names. American Mineralogist, 96 (5) 936-945 doi:10.2138/am.2011.576DOI: 10.2138/am.2011.576
  5. 2015(2015) Metarauchite. Handbook of Mineralogy. Mineralogical Society of America
