Metaswitzerite

Mn2+3(PO4)2 · 4H2O
IMA status
  • Approved
IMA symbol
Msw
Discovered
1967
Also known as
  • Metaswitzeriet

Where it forms, where it's found

Geological setting

Fracture surfaces in granite pegmatite.

Granite pegmatite, zinc-bearing phosphorus deposits

Type locality
Foote Lithium Co. Mine
  1. Kings Mountain
  2. Cleveland County
  3. North Carolina
  4. USA

35.2111°, -81.3556°

28recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Dark brown to light golden brown · pale pink · white
Streak
White
Tenacity
flexible
Cleavage
Perfect

Perfect on (100) Fair on (010)

Density
2.95 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 42° · 2V calc = 42°
Refractive index
1.602 – 1.632
Surface relief
Moderate
Principal indices
nα 1.602 · nβ 1.628 · nγ 1.632
Birefringence
0.030
Pleochroism
Visible

Light to dark red-brown

Dispersion
very weak r < v
Extinction
Y = b; Z ∧ c = 10.5°.
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/a
Cell parameters
a = 17.099 Å · b = 12.694 Å · c = 8.282 Å
Cell angles
β = 95.91 °
Ratio a:b:c
1 : 0.742 : 0.484
Z
8
Morphology

Tabular to bladed bent crystals. Forms include (100) (dominant), and (210) (well developed). Common are (410), (101), (101), and (111) and less common (111).

Type-locality form

Flat rosettes, as small micaceous masses and as rare bladed crystals to 3 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
44.98%
25MnManganeseManganese354.938164.814
38.62%
15PPhosphorusPhosphorus230.97461.948
14.51%
1HHydrogenHydrogen81.0088.064
1.89%
Total426.814100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Metaswitzeriet

In other languages

German
IMA 1981-027a · Metaswitzerit
Italian
metaswitzerite
Russian
метасвитцерит

Classification

Strunz
10th ed.

8.CE.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.25MetaswitzeriteSpecies
Dana
8th ed.

40.03.05.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.03A3(XO4)2·xH2OType
  • 40.03.05Ludlamite GroupGroup
  • 40.03.05.02MetaswitzeriteSpecies
CIM

19.12.1

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.1MetaswitzeriteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1967Leavens, Peter B., White, John S. (1967) Switzerite, (Mn,Fe)3(PO4)2·4H2O, a new mineral. American Mineralogist, 52 (11-12) 1595-1602
  2. 1979Fanfani, L., Zanazzi, P. F. (1979) Switzerite: Its chemical formula and crystal structure. TMPM Tschermaks Mineralogische und Petrographische Mitteilungen, 26 (4). 255-269 doi:10.1007/bf01089840DOI: 10.1007/bf01089840
  3. 1986White, J. S., Leavens, P. B., Zanazzi, P. F. (1986) Switzerite redefined as Mn3(PO4)2·7H2O, and metaswitzerite, Mn3(PO4)2·4H2O. American Mineralogist, 71 (9-10) 1221-1223
  4. 1986Zanazzi, P. F., Leavens, P. B., White, J. S. (1986) Crystal structure of switzerite, Mn3(PO4)2·7H2O, and its relationship to metaswitzerite, Mn3(PO4)2·4H2O. American Mineralogist, 71 (9-10) 1224-1228
  5. 2005(2005) Metaswitzerite. Handbook of Mineralogy. Mineralogical Society of America
