Switzerite

Mn2+3(PO4)2 · 7H2O
IMA status
  • Approved
IMA symbol
Swt
Also known as
  • Switzeriet

Where it forms, where it's found

Geological setting

A late stage hydrothermal mineral formed in fractures and seams cutting granite pegmatite.

Type locality
Foote Lithium Co. Mine
  1. Kings Mountain
  2. Cleveland County
  3. North Carolina
  4. USA

35.2111°, -81.3556°

27recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Pearly
Transparency
Transparent · Translucent
Colour
Pale pink · pinkish brown

Becoming yellowish or brownish on dehydration.

Tenacity
brittle
Cleavage
Perfect

(001)

Somewhat flexible.

Density
2.535 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70° · 2V calc = 66°
Refractive index
1.56 – 1.58
Surface relief
Moderate
Principal indices
nα 1.560 · nβ 1.574 · nγ 1.580
Dispersion
r > v moderate
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 8.528(4) Å · b = 13.166(5) Å · c = 11.812(4) Å
Cell angles
β = 110.05(3) °
Ratio a:b:c
1 : 1.544 : 1.385
Z
4
Morphology

Bladed crystals, flattened on (100) and elongated on [001].

Type-locality form

Crystals, tabular on (001) or bladed and elongated on (100). The size is less than 5 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
49.91%
25MnManganeseManganese354.938164.814
34.28%
15PPhosphorusPhosphorus230.97461.948
12.88%
1HHydrogenHydrogen141.00814.112
2.93%
Total480.859100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Switzeriet

In other languages

French
Switzérite
German
IMA 1966-042 · Switzerit
Spanish
Switzerita
Italian
Switzerite
Russian
свитцерит

Classification

Strunz
10th ed.

8.CE.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.25SwitzeriteSpecies
Dana
8th ed.

40.03.05.04

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.03A3(XO4)2·xH2OType
  • 40.03.05Ludlamite GroupGroup
  • 40.03.05.04SwitzeriteSpecies
CIM

19.12.23

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.23SwitzeriteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1967Leavens, Peter B., White, John S. (1967) Switzerite, (Mn,Fe)3(PO4)2·4H2O, a new mineral. American Mineralogist, 52 (11-12) 1595-1602
  2. 1986White, J. S., Leavens, P. B., Zanazzi, P. F. (1986) Switzerite redefined as Mn3(PO4)2·7H2O, and metaswitzerite, Mn3(PO4)2·4H2O. American Mineralogist, 71 (9-10) 1221-1223
  3. 1986Zanazzi, P. F., Leavens, P. B., White, J. S. (1986) Crystal structure of switzerite, Mn3(PO4)2·7H2O, and its relationship to metaswitzerite, Mn3(PO4)2·4H2O. American Mineralogist, 71 (9-10) 1224-1228
  4. 2005(2005) Switzerite. Handbook of Mineralogy. Mineralogical Society of America
