Nacrite

Al2Si2O5(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ncr
Discovered
1807
Also known as
  • Nacrite (of Brongniart)
  • Nakrito

Where it forms, where it's found

Type locality
Einigkeit Mine
  1. Brand-Erbisdorf
  2. Mittelsachsen
  3. Saxony
  4. Germany

50.8717°, 13.3194°

126recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy · Pearly
Colour
White · grey · yellowish · brownish · etc.
Streak
White

Optical

Optical type
Biaxial (-) · 2V measured = 40° · 2V calc = 48°
Refractive index
1.557 – 1.563
Surface relief
Moderate
Principal indices
nα 1.557 · nβ 1.562 · nγ 1.563
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#3
Cell parameters
a = 5.14 Å · b = 8.94 Å · c = 14.4 Å
Cell angles
β = 113.7 °
Ratio a:b:c
1 : 1.739 : 2.802
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
55.78%
14SiSiliconSilicon228.08556.170
21.76%
13AlAluminiumAluminium226.98253.964
20.90%
1HHydrogenHydrogen41.0084.032
1.56%
Total258.157100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Nacrite (of Brongniart)
  • Nakrito

In other languages

French
Nacrite
German
Nakrit
Spanish
Nacrita · Piedra Tianhuang
Italian
nacrite
Japanese
ナクル石
Chinese
珍珠石

Classification

Strunz
10th ed.

9.ED.05

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.05NacriteSpecies
CIM

15.7

  • 15Silicates of AluminumClass
  • 15.7— unnamed intermediate level —Group
  • 15.7NacriteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1807Brongniart, A. (1807) Traité élémentaire de Minéralogie, Paris I, 505.
  2. 1930Ross, Clarence S., Kerr, Paul F. (1930) Dickite, a kaolin mineral. American Mineralogist, 15 (1) 34-39
  3. 1962Aderca, B. (1962) Contribution à la microtectonique houillère: fentes penniformes avec présence de nacrite. Annales de la Société géologique de Belgique, 85, B309.
  4. 1962Van Tassel, R. (1962) Occurrence de nacrite dans les fissures des veinules de charbon. Annales de la Société géologique de Belgique, 85, B319.
  5. 1963Bailey, S. W. (1963) Polymorphism of the kaolin minerals. American Mineralogist, 48 (11-12) 1196-1209
