Nanpingite

CsAl2(Si3Al)O10(OH)2
IMA status
  • Approved
IMA symbol
Npg
Discovered
1988
Also known as
  • Nanpingiet

Where it forms, where it's found

Type locality
Pegmatite No. 31
  1. Nanping pegmatite field
  2. Yanping District
  3. Nanping
  4. Fujian
  5. China

26.6572°, 118.1022°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
White to silver white
Streak
White
Tenacity
elastic
Cleavage
Perfect

(001)

Density
3.11 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 46° · 2V calc = 36°
Refractive index
1.551 – 1.588
Surface relief
Moderate
Principal indices
nα 1.551 · nβ 1.584 · nγ 1.588
Dispersion
r > v weak
Michel-Lévy diagramhighlighted lineδ = 0.0370
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]370 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation370 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 5.362(3) Å · b = 8.86(1) Å · c = 21.42(1) Å
Cell angles
β = 95.77(2) °
Ratio a:b:c
1 : 1.652 : 3.995
Z
4
Morphology

Rarely as pseudohexagonal crystals; as radiating and comb aggregates, and scales and plates, to 1 cm.

Type-locality form

Plates and scales up to 10 mm in diameter, radiating and comb aggregates, rarely as pseudo hexagonal crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
39.01%
55CsCaesiumCaesium1132.905132.905
27.01%
14SiSiliconSilicon328.08584.255
17.12%
13AlAluminiumAluminium326.98280.946
16.45%
1HHydrogenHydrogen21.0082.016
0.41%
Total492.110100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • K
  • Rb
  • H2O

Synonyms

  • Nanpingiet

In other languages

German
IMA 1987-006 · Nanpingit
Italian
Nanpingite
Portuguese
IMA1987-006 · Nanpingita

Classification

Strunz
10th ed.

9.EC.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.15NanpingiteSpecies
Dana
8th ed.

71.02.2a.08

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.02Sheets of 6-membered rings with 2:1 layersType
  • 71.02.2a— unnamed intermediate level —Group
  • 71.02.2a.08NanpingiteSpecies
CIM

16.5.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.5— unnamed intermediate level —Group
  • 16.5.2NanpingiteSpecies

Group, growth & confusion

In the same group
6 members

Literature, links & citation

Citations
  1. 1988Yang, Y., Ni, Y., Wang, L., Wang, W., Zhang, Y., Chen, C. (1988) Nanpingite - A new cesium mineral. Acta Petrologica et Mineralogica: 7: 49-58. (in Chinese with English abstract)
  2. 1988Yang, Y., Ni, Y., Wang, L., Wang, W., Zhang, Y., Chen, C. (1988) Nanpingite - A new cesium mineral. Acta Petrologica et Mineralogica: 7: 49-58.
  3. 1990Jambor, John L., Vanko, David A. (1990) New Mineral Names. American Mineralogist, 75 (5-6) 706-713
  4. 1996Ni, Yunxiang, Hughes, John M. (1996) The crystal structure of nanpingite-2M2, the Cs end-member of muscovite. American Mineralogist, 81 (1) 105-110 doi:10.2138/am-1996-1-213 DOI: 10.2138/am-1996-1-213
  5. 1998Rieder, M., Cavazzini, G., D’Yakonov, Y.S., Frank-Kamenetskii, V.A., Gottardt, G., Guggenheim, S., Koval, P.V., Muller, G., Neiva, A.M.R., Radoslovich, E.W., Robert, J.L., Sassi, F.P., Takeda, H., Weiss, Z., Wones, D.R. (1998) Nomenclature of the micas. The Canadian Mineralogist, 36 (3) 905-912
