Chromphyllite

KCr2(AlSi3O10)(OH)2
IMA status
  • Approved
IMA symbol
Crp
Also known as
  • Chromphylliet
  • Cromfilita
  • IMA1995-052

Where it forms, where it's found

Geological setting

Parametamorphic in Cr-enriched layers in quartz-diopside rocks.

Type locality
Kaber's pit
  1. Pokhabikha River Valley
  2. Slyudyanka
  3. Russia

51.6356°, 103.6481°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Emerald-green
Streak
Whitish green
Cleavage
Perfect

(001)

Density
2.88 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 31° · 2V calc = 30°
Refractive index
1.619 – 1.673
Surface relief
Moderate
Principal indices
nα 1.619 · nβ 1.669 · nγ 1.673
Pleochroism
Strong

Z = emerald or bluish green, Y = brownish green, X = blue-green

Dispersion
r > v distinct
Extinction
b = Z, a ≅ Y, X ≅ ⊥(001), optic axial plane ⊥(001).
Notes

Positive elongation.

Michel-Lévy diagramhighlighted lineδ = 0.0540
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]540 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation540 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 5.32(2) Å · b = 9.07(2) Å · c = 20.50(7) Å
Cell angles
β = 95.6(2) °
Ratio a:b:c
1 : 1.705 : 3.853
Z
4
Morphology

Some grains are subhedral, pseudohexagonal, showing (110), (010), and (001).

Type-locality form

Plates and flakes, 0.3–0.4 mm.

Comment

2M1 polytype. also orthorhombic, space group C2c.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
42.82%
24CrChromiumChromium251.996103.992
23.20%
14SiSiliconSilicon328.08584.255
18.79%
19KPotassiumPotassium139.09839.098
8.72%
13AlAluminiumAluminium126.98226.982
6.02%
1HHydrogenHydrogen21.0082.016
0.45%
Total448.331100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chromphylliet
  • Cromfilita
  • IMA1995-052

In other languages

German
Chromphyllit · IMA 1995-052
Italian
Chromphyllite · Cromfillite

Classification

Strunz
10th ed.

9.EC.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.15ChromphylliteSpecies
Dana
8th ed.

71.02.03.04

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.02Sheets of 6-membered rings with 2:1 layersType
  • 71.02.03Cuprorivaite groupGroup
  • 71.02.03.04ChromphylliteSpecies

Group, growth & confusion

In the same group
6 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1997Reznitsky, L.Z., Sklyarov, E.V., Ushchapovskaya, Z.F., Nartova, N.V., Evsyunin, V.G., Kashaev, A.A., Suvorova, L.F. (1997) Chromphyllite KCr2[AlSi3O10](OH,F)2 - a new dioctahedral mica. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 126(2), 110-119.
  2. 1997Evsyunin, V.G., Kashaev, A.A., Rastsvetaeva, R.K. (1997) Crystal structure of a new representative of Cr micas. Crystallography Reports, 42, 571-574.
  3. 1998Rieder, M., Cavazzini, G., D’Yakonov, Y.S., Frank-Kamenetskii, V.A., Gottardt, G., Guggenheim, S., Koval, P.V., Muller, G., Neiva, A.M.R., Radoslovich, E.W., Robert, J.L., Sassi, F.P., Takeda, H., Weiss, Z., Wones, D.R. (1998) Nomenclature of the micas. The Canadian Mineralogist, 36 (3) 905-912
  4. 1998Jambor, J.L., Puziewicz, J., Roberts, A.C. (1998) New mineral names. American Mineralogist, 83, 652-656.
  5. 2001New Minerals (2001).
