Natrouranospinite

Na2(UO2)2(AsO4)2 · 5H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Nusp
Discovered
1957
Also known as
  • Ellweilerit
  • Ellweilerite
  • Meta-natrium-uranospinite
  • +4 more

Where it forms, where it's found

Geological setting

Oxidized zone of uranium-sulfide deposit hosted by felsite porphyry and tufaceous breccia.

Type locality
Bota-Burum U deposit
  1. Alakol District
  2. Jetisu Region
  3. Kazakhstan

45.6947°, 81.8695°

17recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Lemon-yellow · straw-yellow · yellow-green
Streak
Pale yellow
Tenacity
brittle
Cleavage
Perfect

(001), distinct on (010).

Fracture
Micaceous
Density
3.846 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.585 – 1.612
Surface relief
Moderate
Principal indices
nω 1.612 · nε 1.585
Birefringence
0.027
Pleochroism
Weak

X = colorless, Y = Z = yellow.

UV response
Fluoresces bright yellow green in SW and LW
Michel-Lévy diagramhighlighted lineδ = 0.0270
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]270 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation270 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P4/nmm
Cell parameters
a = 7.12 Å · c = 8.61 Å
Z
1
Type-locality form

Fibrous to crudely platy crystals in aggregates and crusts.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
49.90%
8OOxygenOxygen1715.999271.983
28.51%
33AsArsenicArsenic274.922149.844
15.71%
11NaSodiumSodium222.99045.980
4.82%
1HHydrogenHydrogen101.00810.080
1.06%
Total953.945100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca

Synonyms

  • Ellweilerit
  • Ellweilerite
  • Meta-natrium-uranospinite
  • Na Uranospinit
  • Na Uranospinite
  • Natrouranospiniet
  • Sodium uranospinite

In other languages

German
Natrouranospinit
Italian
Natrouranospinite · Sodio-uranospinite

Classification

Strunz
10th ed.

8.EB.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.15NatrouranospiniteSpecies
Dana
8th ed.

40.2a.06.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.06— unnamed intermediate level —Group
  • 40.2a.06.01NatrouranospiniteSpecies
CIM

20.7.2

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.7Arsenates of UGroup
  • 20.7.2NatrouranospiniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1957Kopchenova, E.V., Skvortsova, K.V. (1957) Sodium Uranospinite. Doklady Akademii Nauk SSSR, 114, 634-636.
  2. 1958Fleischer, M. (1958) New Mineral Names. American Mineralogist, 43 (3-4). 378-387
  3. 2005(2005) Natrouranospinite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2008Burke, Ernst A. J. (2008) Tidying up mineral names: an IMA-CNMNC scheme for suffixes, hyphens and diacritical marks. The Mineralogical Record, 39 (2) 131-135
  5. 2009Čejka, Jiří, Sejkora, Jiří, Frost, Ray L., Keeffe, Eloise C. (2009) Raman spectroscopic study of the uranyl mineral natrouranospinite (Na2,Ca)[(UO2)(AsO4)]2·5H2O. Journal of Raman Spectroscopy, 40 (11) 1521-1526 doi:10.1002/jrs.2233DOI: 10.1002/jrs.2233
