Packratite

Ca11(As3+V5+10V4+2As5+6O51)2 · 83H2O
IMA status
  • Approved
IMA symbol
Pkt
IMA approved
2014
Also known as
  • IMA2014–059
  • Packratiet

Where it forms, where it's found

Type locality
Packrat Mine
  1. Beaver Mesa
  2. Gateway Mining District
  3. Mesa County
  4. Colorado
  5. USA

38.6476°, -109.0471°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Very dark greenish blue
Streak
Grayish blue
Tenacity
brittle
Cleavage
Imperfect/Fair

(001), (110), and {1–10} fair

Density
2.36 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60.7°
Refractive index
1.625 – 1.629
Surface relief
Moderate
Principal indices
nα 1.625 · nβ 1.628 · nγ 1.629
Pleochroism
Non-pleochroic

non-pleochroic dark blue

Dispersion
r<v, moderate
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 18.0572(4) Å · b = 19.4126(4) Å · c = 24.0586(17) Å
Cell angles
α = 87.364(6) ° · β = 86.266(6) ° · γ = 79.267(6) °
Ratio a:b:c
1 : 1.075 : 1.332
Unit cell volume
8263.4 ų
Z
2
Morphology

Flattened on (110) and elongated on [001]

Type-locality form

Very dark blue to greenish-blue blades up to about 1 mm long, striated lengthwise, and grow in sub-parallel and divergent intergrowths. Also as pearly green, botryoidal aggregates.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen18515.9992959.815
50.69%
23VVanadiumVanadium2450.9421222.608
20.94%
33AsArsenicArsenic1474.9221048.908
17.96%
20CaCalciumCalcium1140.078440.858
7.55%
1HHydrogenHydrogen1661.008167.328
2.86%
Total5839.517100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2014–059
  • Packratiet

In other languages

German
IMA 2014-059 · Packratit
Italian
packratite

Classification

Strunz
10th ed.

8.FD.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.FPolyphosphates, Polyarsenates, [4]-PolyvanadatesDivision
  • 8.FDPolyphosphates, etc., with OH and H2OGroup
  • 8.FD.10PackratiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC), CNMNC Newsletter No. 22. Mineralogical Magazine, 78 (5) 1241-1248 doi:10.1180/minmag.2014.078.5.10DOI: 10.1180/minmag.2014.078.5.10
  2. 2016Kampf, Anthony R., Hughes, John M., P. Nash, Barbara, Marty, Joe (2016) Vanarsite, packratite, morrisonite, and gatewayite: four new minerals containing the [As3+V4+,5+12As5+6O51] heteropolyanion, a novel polyoxometalate cluster. The Canadian Mineralogist, 54 (1) 145-162 doi:10.3749/canmin.1500062 DOI: 10.3749/canmin.1500062
  3. 2016faculty.utah.edu (n.d.) https://faculty.utah.edu/u0035233-BARBARA_P_NASH/bibliography/index.hml
  4. 2017(2017) Packratite. Handbook of Mineralogy. Mineralogical Society of America
