Pyrosmalite-(Fe)

Fe2+8Si6O15(OH)10
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pys-Fe
Discovered
1808
Also known as
  • Ferropyrosmalit
  • Ferropyrosmalita
  • Ferropyrosmalite
  • +2 more

Where it forms, where it's found

Type locality
Bjelke Mine
  1. Nordmark Odal Field
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8167°, 14.0997°

36recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond

Optical

Optical type
Uniaxial (-)
Refractive index
1.64 – 1.68
Surface relief
High
Principal indices
nω 1.68 · nε 1.64
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#97
Cell parameters
a = 13.3165(2) Å · c = 7.0845(2) Å
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron855.845446.760
43.57%
8OOxygenOxygen2515.999399.975
39.01%
14SiSiliconSilicon628.085168.510
16.44%
1HHydrogenHydrogen101.00810.080
0.98%
Total1025.325100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mg

Synonyms

  • Ferropyrosmalit
  • Ferropyrosmalita
  • Ferropyrosmalite
  • Pyrosmaliet-(Fe)
  • Pyrosmalit-(Fe)

In other languages

German
IMA 85-L · Pyrosmalith-(Fe)
Italian
Ferropirosmalite · Ferropyrosmalite · Pirosmalite- · pirosmalite-(Fe)

Classification

Strunz
10th ed.

9.EE.10

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EESingle tetrahedral nets of 6-membered rings connected by octahedral nets or octahedral bandsGroup
  • 9.EE.10Pyrosmalite-(Fe)Species
Dana
8th ed.

72.04.1a.01

  • 72Phyllosilicates Two-dimensional Infinite Sheets with Other Than Six-membered RingsClass
  • 72.04Two-Dimensional Infinite Sheets with Other Than Six-Membered Rings with 4-, 6-, and 12-membered ringsType
  • 72.04.1a— unnamed intermediate level —Group
  • 72.04.1a.01Pyrosmalite-(Fe)Species
CIM

17.3.12

  • 17Silicates Containing other AnionsClass
  • 17.3Silicates with chloride (including aluminosilicates)Group
  • 17.3.12Pyrosmalite-(Fe)Species

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1808Moll, C.E.F. (1808) Vorläufige Notiz von einigen neuen nordischen Fossilien; von dem Herrn Cammersecretär Hausmann zu Braunschweig mitgetheilt. 1. Pirodmalit. in Efemeriden der Berg und Hüttenkunde, Steinischen Buchhandlung (Nürnberg), 390-393.
  2. 1808Karsten, D.L.G. (1808) Pyrosmalith. in Mineralogische Tabellen 2nd, Heinrich August Rottman (Berlin), 103-103.
  3. 1983Kato, T., Takéuchi, Y. (1983) The pyrosmalite group of minerals: I. Structure refinement of manganpyrosmalite. The Canadian Mineralogist, 21, 1-6.
  4. 1986Vaughan, J.P. (1986) The iron end-member of the pyrosmalite series from the Pegmont lead-zinc deposit, Queensland. Mineralogical Magazine, 50, 527-531.
  5. 1987Vaughan, J.P. (1987) Ferropyrosmalite and nomenclature in the pyrosmalite series. Mineralogical Magazine, 51, 174-174.
