Rhabdophane-(La)

La(PO4) · H2O
IMA status
  • Approved
IMA symbol
Rha-La
Discovered
1883
Also known as
  • Rhabdophaan-(La)
  • Scovillit
  • Scovillita
  • +1 more

Where it forms, where it's found

Geological setting

Limonitic iron ore deposit.

Type locality
Scoville Mine
  1. Salisbury
  2. Litchfield County
  3. Connecticut
  4. USA

42.0170°, -73.4413°

22recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Greasy
Colour
Brown · pinkish · yellowish-white

Optical

Optical type
Uniaxial (+)
Refractive index
1.654 – 1.703
Surface relief
High
Principal indices
nω 1.654 · nε 1.703
Michel-Lévy diagramhighlighted lineδ = 0.0490
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]490 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation490 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#119
Cell parameters
a = 7.03(1) Å · c = 6.41(1) Å
Z
3
Type-locality form

Incrustations

Comment

Space group by analogy with rhabdophane-(Ce).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
57LaLanthanumLanthanum1138.905138.905
55.14%
8OOxygenOxygen515.99979.995
31.76%
15PPhosphorusPhosphorus130.97430.974
12.30%
1HHydrogenHydrogen21.0082.016
0.80%
Total251.890100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Rhabdophaan-(La)
  • Scovillit
  • Scovillita
  • Skovillit

In other languages

German
Rhabdophan-(La)
Italian
Rabdofane- · rhabdophane-(La)

Classification

Strunz
10th ed.

8.CJ.45

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CJWith only large cationsGroup
  • 8.CJ.45Rhabdophane-(La)Species
Dana
8th ed.

40.04.07.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.04(AB)5(XO4)2·xH2OType
  • 40.04.07Rhabdophane GroupGroup
  • 40.04.07.02Rhabdophane-(La)Species
CIM

19.9.7

  • 19PhosphatesClass
  • 19.9Phosphates of rare earths and ScGroup
  • 19.9.7Rhabdophane-(La)Species

Group, growth & confusion

In the same group
6 members

Literature, links & citation

Citations
  1. Dumler, F.L., Skornyakova, K.P.; Shul’ga, G.G. (1969) Lanthanum rhabdophane in the weathered mantle on limestones – a new type of rare earth mineralization. Zap. Vses. Mineral. Obshch., 98, 593-600 (in Russian).
  2. 1883Brush, G.J., Penfield, S.L. (1883) On scovillite, a new phosphate of didymium, yttrium and other rare earths, from Salisbury, Conn. American Journal of Science, 25, 459-463. (as scovillite)
  3. 1884Brush, G.J., Penfield, S.L. (1884) On the identity of scovillite with rhabdophane. American Journal of Science: 27(159): 200-201 (as scovillite).
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1970Dumler, F.L., Skornyakova, K.P., Shul'ga, G.G. (1970) Lanthanum rhabdophane in the weathered mantle on limestones—a new type of rare earth mineralization. International Geology Review, 12 (9) 1140-1145 doi:10.1080/00206817009475334DOI: 10.1080/00206817009475334
