Schultenite

Pb(AsO3OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Slt
Discovered
1926
Also known as
  • Schulteniet

Where it forms, where it's found

Geological setting

Found in the oxidized zones of lead deposits.

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

40recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · colourless in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (010), good.

Density
5.943 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 58° · 2V calc = 60°
Refractive index
1.89 – 1.976
Surface relief
Very high
Principal indices
nα 1.890 · nβ 1.910 · nγ 1.976
Birefringence
0.086
Dispersion
strong
Extinction
X=b, Y∧c = -24°, Z∧c = 66°.
UV response
Dull yellow in LW UV
Michel-Lévy diagramhighlighted lineδ = 0.0860
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]860 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation860 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/a
Cell parameters
a = 5.842 Å · b = 6.758 Å · c = 4.858 Å
Cell angles
β = 95.4 °
Ratio a:b:c
1 : 1.157 : 0.832
Z
2
Morphology

Crystals flattened (010); commonly rhomboidal and resembling gypsum. (010) striated [001], (001) striated [100].

Twinning

Fishtail twins observed

Type-locality form

Thin crystal plates, transparent and colourless, to 1 cm across with a thickness of 1 mm.

Comment

Ranges: a 5.820 b 6.743 c4.847, beta 95.34-95.9

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
59.69%
33AsArsenicArsenic174.92274.922
21.58%
8OOxygenOxygen415.99963.996
18.44%
1HHydrogenHydrogen11.0081.008
0.29%
Total347.126100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Schulteniet

In other languages

French
schulténite
German
Schultenit
Italian
Schultenite

Classification

Strunz
10th ed.

8.AD.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.30SchulteniteSpecies
Dana
8th ed.

37.01.02.01

  • 37Anhydrous Acid Phosphates, Arsenates and VanadatesClass
  • 37.01MiscellaneousType
  • 37.01.02— unnamed intermediate level —Group
  • 37.01.02.01SchulteniteSpecies
CIM

20.5.2

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.5Arsenates of Ti and PbGroup
  • 20.5.2SchulteniteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1904de Schulten, A. (1904) Production artificielle de monétites de baryum, de plomb et de strontium et de monétites arséniées de plomb et de strontium. Bulletin de la Société française de Minéralogie: 27(6): 109-123 (113).
  2. 1908Groth, P. (1908) Chemische Krystallographie Vol. 2. Wilhem Engelmann.
  3. 1916McDonnell, C. C.; Smith, C. M. (1916) The arsenates of lead. Journal of the American Chemical Society, 38 (10). 2027-2038 doi:10.1021/ja02267a014DOI: 10.1021/ja02267a014
  4. 1926Spencer, L. J., Mountain, E. D. (1926) Schultenite, a new mineral, from South-West Africa. Mineralogical Magazine and Journal of the Mineralogical Society, 21 (115) 149-155 doi:10.1180/minmag.1926.021.115.02 DOI: 10.1180/minmag.1926.021.115.02
  5. 1927Foshag, W.F. (1927) New Mineral Names. American Mineralogist, 12 (7). 295-296
