Sengierite

Cu2(UO2)2(VO4)2(OH)2 · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sgi
Discovered
1949
Also known as
  • Sengieriet

Where it forms, where it's found

Type locality
Luiswishi Mine
  1. Kawama
  2. Kipushi Territory
  3. Haut-Katanga
  4. DR Congo

-11.5132°, 27.4367°

17recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Olive-green · yellowish green
Streak
Light green
Tenacity
brittle
Cleavage
Perfect

On (001), perfect

Density
4.05 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 37 – 39° · 2V calc = 36°
Refractive index
1.76 – 1.97
Surface relief
Very high
Principal indices
nα 1.76 – 1.77 · nβ 1.92 – 1.94 · nγ 1.94 – 1.97
Pleochroism
Visible

X = Bluish green to colourless Y = Olive-green to greenish yellow Z = Yellowish green to colourless

Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.1900
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1900 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1900 nm
Order4th order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 10.599 Å · b = 8.093 Å · c = 10.085 Å
Cell angles
β = 103.42 °
Ratio a:b:c
1 : 0.764 : 0.952
Z
2
Morphology

Crystals six-sided thin plates, flattened on (001), and exhibiting (001), (110), (100), (201), and {111:; also as flaky coatings.

Type-locality form

Small, green, platy crystals

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
45.81%
8OOxygenOxygen2015.999319.980
30.79%
29CuCopperCopper263.546127.092
12.23%
23VVanadiumVanadium250.942101.884
9.81%
1HHydrogenHydrogen141.00814.112
1.36%
Total1039.126100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Sengieriet

In other languages

German
Sengierit
Italian
sengierite
Russian
Сенжьерит

Classification

Strunz
10th ed.

4.HB.10

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HBUranyl SorovanodatesGroup
  • 4.HB.10SengieriteSpecies
Dana
8th ed.

42.06.10.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.06A2(XO4)Zq·xH2OType
  • 42.06.10— unnamed intermediate level —Group
  • 42.06.10.01SengieriteSpecies
CIM

21.4.6

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.4Vanadates of U, Mn, Fe or NiGroup
  • 21.4.6SengieriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1949Vaes, J. F., Kerr, Paul F. (1949) Sengierite, a preliminary description. American Mineralogist, 34 (1-2) 109-120
  2. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  3. 1957Hutton, C. Osborne (1957) Sengierite from Bisbee, Arizona. American Mineralogist, 42 (5-6) 408-411
  4. 1958Frondel, Clifford (1958) Systematic mineralogy of uranium and thorium. Bulletin 1064. US Geological Survey doi:10.3133/b1064 DOI: 10.3133/b1064
  5. 1980Piret, Paul, Declercq, Jean-Paul, Wauters-Stoop, Dominique (1980) Structure cristalline de la sengiérite. Crystal structure of sengierite. Bulletin de Minéralogie, 103 (2) 176-178 doi:10.3406/bulmi.1980.7393DOI: 10.3406/bulmi.1980.7393
