Metatyuyamunite

Ca(UO2)2(VO4)2 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mtyu
Discovered
1953
Also known as
  • Metatyuyamuniet

Where it forms, where it's found

Geological setting

Sedimentary uranium deposit

Type locality
Shiprock District
  1. San Juan County
  2. New Mexico
  3. USA
125recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright yellow
Streak
Yellow
Tenacity
sectile
Cleavage
Perfect

(001)

Density
3.81 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 45° · 2V calc = 44°
Refractive index
1.62 – 1.899
Surface relief
High
Principal indices
nα 1.62 – 1.68 · nβ 1.835 – 1.842 · nγ 1.865 – 1.899
Birefringence
0.2
Pleochroism
Weak

X = colorless Y= very pale canary yellow Z = pale canary yellow

Dispersion
r > v strong
Extinction
XYZ = cab
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.2000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2000 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2000 nm
Order4th order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 10.54 Å · b = 8.49 Å · c = 17.34 Å
Ratio a:b:c
1 : 0.806 : 1.645
Z
4
Morphology

Usually earthy granular, also rhombic platy crystals.

Type-locality form

Scales and laths, radial aggregates. Massive, compact to cryptocrystalline. Powdery.

Comment

Pnam

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
55.10%
8OOxygenOxygen1515.999239.985
27.77%
23VVanadiumVanadium250.942101.884
11.79%
20CaCalciumCalcium140.07840.078
4.64%
1HHydrogenHydrogen61.0086.048
0.70%
Total864.053100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Metatyuyamuniet

In other languages

German
Metatyuyamunit
Italian
metatyuyamunite

Classification

Strunz
10th ed.

4.HB.25

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HBUranyl SorovanodatesGroup
  • 4.HB.25MetatyuyamuniteSpecies
Dana
8th ed.

40.2a.26.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.26— unnamed intermediate level —Group
  • 40.2a.26.02MetatyuyamuniteSpecies
CIM

21.4.7

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.4Vanadates of U, Mn, Fe or NiGroup
  • 21.4.7MetatyuyamuniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1953Weeks, A.D., Thompson, M.E. (1953) Identification and Occurrence of Uranium and Vanadium Minerals from the Colorado Plateaus. Trace Elements Investigations Report 334, United States Geological Survey: 69 pgs.
  2. 1953Weeks, A.D., Thompson, M.E., Thompson, R.B. (1953) Program & Abstracts of the Mineralogical Society of America, p. 43.
  3. 1954Fleischer, M. (1954) New mineral names. American Mineralogist, 39 (11-12). 1037-1040
  4. 1954Weeks, A.D., Thompson, M.E. (1954) Identification and occurrence of uranium and vanadium minerals from the Colorado Plateaus: Tyutamunite and metatyuyamunite. Bulletin of the United States Geological Survey 1009-B: 37-38.
  5. 1954Weeks, A.D., Thompson, M.E., Thompson, R.B., Jr. (1954) Mineral associations and types of uranium ores of the Colorado plateaus. American Mineralogist: 39: 349-349. (abstract)
