Skogbyite

Zr(Mg2Mn3+4)SiO12
IMA status
  • Approved
IMA symbol
Skb
IMA approved
2023
Also known as
  • Skogbyiet

Where it forms, where it's found

Geological setting

skogbyite formed during regional metamorphism of a pre-existing, weakly Mn(–Fe)-mineralised carbonate–silicate rock.

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
grey
Streak
brownish grey
Tenacity
brittle
Cleavage
None Observed
Density
4.821 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
bluish grey
Anisotropism
weak
Bireflectance
weak
Internal reflections
none
Tropism
Anisotropic
UV response
none
Notes

the reflectivity of skogbyite should be similar to that of gatedalite, i.e. between ca. 17 % and 21 % in air (Hålenius and Bosi, 2015), and is slightly lower than the reflectivities of neighbouring Fe–Mn oxide minerals, as observed in plane-polarised light.

Crystallography

Crystal system
Tetragonal
Space group
I41/acd
Cell parameters
a = 9.4914(4) Å · c = 18.9875(10) Å
Z
8
Twinning

none

Parting
none observed
Type-locality form

very small, mostly ≤ 60 µm, rounded to subhedral grey crystals

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese454.938219.752
37.91%
8OOxygenOxygen1215.999191.988
33.12%
40ZrZirconiumZirconium191.22491.224
15.74%
12MgMagnesiumMagnesium224.30548.610
8.39%
14SiSiliconSilicon128.08528.085
4.84%
Total579.659100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Skogbyiet

In other languages

German
Skogbyit

Classification

Strunz
10th ed.

9.AG.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.05SkogbyiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2024Nishio-Hamane, Daisuke; Momma, Koichi; Shimobayashi, Norimasa; Mills, Stuart J.; Ohnishi, Masayuki; Kobayashi, Toshinori (2024) Miyawakiite-(Y), IMA 2024-003, in IMA Commission on New Minerals, Nomenclature and Classification (CNMNC). Mineralogical Magazine, 88 (2). 203-209 doi:10.1180/mgm.2024.5DOI: 10.1180/mgm.2024.5
  2. 2025Jonsson, E.; H\aalenius, U.; Majka, J.; Bosi, F. (2025) Skogbyite, Zr(Mg₂Mn³⁺₄)SiO₁₂, a new zirconium mineral in the braunite group from Långban, Bergslagen, Sweden. European Journal of Mineralogy, 37 (2). 269-277 doi:10.5194/ejm-37-269-2025DOI: 10.5194/ejm-37-269-2025
