Abswurmbachite

Cu2+Mn3+6O8(SiO4)
IMA status
  • Approved
IMA symbol
Abs
Discovered
1990
IMA approved
1990
Also known as
  • Abswurmbachitt
  • IMA1990-007

Where it forms, where it's found

Geological setting

In very low-grade, high pressure metamorphic quartzites

In very low-grade, high-pressure metamorphic Mn, Al-rich quartzites.

Type locality
Mili
  1. Dirfys-Messapia
  2. Euboea
  3. Central Greece
  4. Greece

38.7230°, 23.7393°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Brownish black
Tenacity
brittle
Cleavage
None Observed
Density
4.96 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
Gray
Anisotropism
Weak
Internal reflections
None
Tropism
Anisotropic
Reflectance R%
(20.8, 21.2, 7.54, 7.88) 470, (19.6, 20.0, 6.87, 7.16) 546, (19.2, 19.7, 6.56, 6.92) 589, (18.7, 19.2, 6.24, 6.58) 650

Crystallography

Crystal system
Tetragonal
Space group
#177
Cell parameters
a = 9.406 Å · c = 18.546 Å
Unit cell volume
1640.82 ų
Z
8
Type-locality form

Anhedral grains to 50 microns.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese654.938329.628
53.75%
8OOxygenOxygen1215.999191.988
31.31%
29CuCopperCopper163.54663.546
10.36%
14SiSiliconSilicon128.08528.085
4.58%
Total613.247100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • (Al, Ti, Cu, Mg, Ca)

Synonyms

  • Abswurmbachitt
  • IMA1990-007

In other languages

French
Abswurmbachite
German
Abswurmbachit · IMA 1990-007
Spanish
Abswurmbachita
Italian
abswurmbachite
Chinese
硅锰铜石
Russian
Абсвюрмбахит
Arabic
أبسويرمباشيت

Classification

Strunz
10th ed.

9.AG.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.05AbswurmbachiteSpecies
Dana
8th ed.

07.05.01.04

  • 07Multiple OxidesClass
  • 07.05(AB)2X3Type
  • 07.05.01Humite group (Tetragonal: I41/acd) containing SiGroup
  • 07.05.01.04AbswurmbachiteSpecies
CIM

14.18.6

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.6AbswurmbachiteSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
8 minerals

Literature, links & citation

Citations
  1. 1991Reinecke, T., Tillmanns, E. & Bernhardt, H.-J. (1991): Abswurmbachite, Cu2+Mn3+[O8/SiO4], a new mineral of the braunite group: natural occurrence, synthesis and crystal structure. Neues Jahrbuch für Mineralogie Abhandlungen, 163, 117-143.
  2. 1992Jambor, John L. (1992) New Mineral Names. American Mineralogist, 77 (5-6) 670-675
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2001(2001) Abswurmbachite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2016Anthony, John W., Bideaux, Richard A., Bladh, Kenneth W., Nichols, Monte C. - Eds. (2016) Handbook of Mineralogy. https://www.handbookofmineralogy.org/
