Stanleyite

V4+O(SO4) · 6H2O
IMA status
  • Approved
IMA symbol
Stl
Discovered
1980
IMA approved
1980
Also known as
  • IMA1980-042
  • Stanleyiet

Where it forms, where it's found

Geological setting

Vanadium ore

Type locality
Ragra Mine
  1. Huayllay District
  2. Pasco Province
  3. Pasco
  4. Peru

-10.8610°, -76.5722°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 1.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light blue to greenish blue
Streak
White
Density
1.95 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 88°
Refractive index
1.505 – 1.533
Surface relief
Moderate
Principal indices
nα 1.505 · nβ 1.519 · nγ 1.533
Pleochroism
Visible

X = Y = blue; Z = very pale blue.

Dispersion
relatively weak
Notes

Absorption: X = Y > Z.

Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 12.12 Å · b = 9.71 Å · c = 14.92 Å
Ratio a:b:c
1 : 0.801 : 1.231
Z
8
Morphology

Minute plates

Type-locality form

1.5 mm fragments or efflorescences.

Comment

May be orthorhombic, monoclinic or triclinic

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
64.92%
23VVanadiumVanadium150.94250.942
18.79%
16SSulfurSulfur132.06032.060
11.83%
1HHydrogenHydrogen121.00812.096
4.46%
Total271.087100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1980-042
  • Stanleyiet

In other languages

German
IMA 1980-042 · Stanleyit
Italian
Stanleyite

Classification

Strunz
10th ed.

7.DE.50

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DEWith only medium-sized cations; unclassifiedGroup
  • 7.DE.50StanleyiteSpecies
Dana
8th ed.

29.06.13.01

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.06AXO4·xH2OType
  • 29.06.13Minasragrite Group (Orthorhombic)Group
  • 29.06.13.01StanleyiteSpecies
CIM

25.8.6

  • 25SulphatesClass
  • 25.8Sulphates of Sb, V, Cr and UGroup
  • 25.8.6StanleyiteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1980Tachez, M., Théobald, F. (1980) Liasons hydrogéne dans les cristaux de sulfate de vanadyle trihydraté (VOSO4.3H2O). Comparaison structurale de quartre sulfates de vanadyle hydratés. Acta Crystallographica, B36, 2873-2880.
  2. 1980Théobald, P.M.T.E.F. (1980) Structure du sulfate de vanadyle hexahydrate. Acta Crystallographica, 36, 249-254.
  3. 1982Livingstone, A. (1982) Stanleyite, a new vanadium sulphate mineral from Peru. Mineralogical Magazine, 45 (337) 163-166 doi:10.1180/minmag.1982.045.337.19 DOI: 10.1180/minmag.1982.045.337.19
  4. 1983Dunn, Pete J., Fleischer, Michael (1983) New mineral names. American Mineralogist, 68 (5-6) 642-645
  5. 2005(2005) Stanleyite. Handbook of Mineralogy. Mineralogical Society of America
