Tsumebite

Pb2Cu(PO4)(SO4)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tsu
Discovered
1912
Also known as
  • Preslite
  • Tsumebiet

Where it forms, where it's found

Geological setting

Oxidation zone.

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

35recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous:
Transparency
Transparent · Translucent
Colour
Emerald-green sometimes bluish green · green in transmitted light.
Streak
White to faint green
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
6.13 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 90° · 2V calc = 90°
Refractive index
1.9 – 1.942
Surface relief
Very high
Principal indices
nα 1.90 · nβ 1.92 · nγ 1.942
Birefringence
0.042
Pleochroism
Weak

Faint. X = Y = very pale blue to colorless; Z = robin’s-egg-blue.

Dispersion
r > v extreme
Extinction
Inclined
UV response
Not fluorescent in UV
Notes

Absorption: Z > X.

Michel-Lévy diagramhighlighted lineδ = 0.0420
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]420 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation420 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 8.69 Å · b = 5.78 Å · c = 7.86 Å
Cell angles
β = 111.87 °
Ratio a:b:c
1 : 0.665 : 0.904
Z
2
Morphology

Crusts of intergrown crystals.

Twinning

Ubiquitous, with twin plane (122), as trillings or more complex groups at times. Often thick tabular on (101) or (110). (011) and (104) usually in oscillatory combination, producing a zig-zag suture in twins at times. (100) narrow and bright, (110) uneven or composite.

Type-locality form

Crust

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
60.41%
8OOxygenOxygen915.999143.991
20.99%
29CuCopperCopper163.54663.546
9.26%
16SSulfurSulfur132.06032.060
4.67%
15PPhosphorusPhosphorus130.97430.974
4.52%
1HHydrogenHydrogen11.0081.008
0.15%
Total685.979100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Preslite
  • Tsumebiet

In other languages

French
tsumébite
German
Tsumebit
Spanish
Tsumebita
Italian
tsumebite

Classification

Strunz
10th ed.

8.BG.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BGWith medium-sized and large cations, (OH, etc.):RO4 = 0.5:1Group
  • 8.BG.05TsumebiteSpecies
Dana
8th ed.

43.04.02.01

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.02Tsumebite GroupGroup
  • 43.04.02.01TsumebiteSpecies
CIM

22.3.15

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.3Phosphates, arsenates or vanadates with sulphatesGroup
  • 22.3.15TsumebiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1912Busz, V.K. (1912) Tsumebit, ein neues Blei-Kupfer-Phosphat von Otavi, Deutsch Süd-West-Afrika. Deutschen Naturforscher und Årtze in Münster, Versammlung: 84: 182-185.
  2. 1912Busz, K. (1912) Tsumebit, ein neues Mineral von Otavi und Zinnsteinkristalle. Deutschen Naturforscher und Årtze in Münster, Versammlung: 84: 230-230.
  3. 1913Rosický, V. (1913) Preslit, ein neues Mineral von Tsumeb in Deutsch-Südwestafrika. Zeitschrift für Kristallographie, 51 (1). 521 doi:10.1524/zkri.1913.51.1.521DOI: 10.1524/zkri.1913.51.1.521
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1938LaForge, Laurence (1938) Crystallography of tsumebite. American Mineralogist, 23 (11) 772-782
