Vanadomalayaite

CaVO(SiO4)
IMA status
  • Approved
IMA symbol
Vmly
IMA approved
1993
Also known as
  • IMA1993-032
  • Vanadomalayaiet

Where it forms, where it's found

Geological setting

Occurs sparingly in a small vein of calcite, quartz, and haradaite that cuts ophiolitic metacherts.

Type locality
Gambatesa Mine
  1. Reppia
  2. Ne
  3. Genoa
  4. Liguria
  5. Italy

44.3597°, 9.4500°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Transparent
Colour
Deep red
Cleavage
Distinct/Good

(110)

Density
3.60 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 17 – 40°
Refractive index
1.95 – 2.105
Surface relief
Very high
Principal indices
nα 1.95 · nγ 2.105
Pleochroism
Visible

X ≈ Y = brownish red-orange, Z = deep greenish blue.

Dispersion
very strong
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.1550
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1550 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1550 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 6.532(2) Å · b = 8.692(3) Å · c = 7.039(2) Å
Cell angles
β = 113.88(1) °
Ratio a:b:c
1 : 1.331 : 1.078
Z
4
Morphology

Prismatic

Twinning

No twinning observed

Type-locality form

Subhedral, prismatic, deep red, isolated grains up to 0.4 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
40.18%
23VVanadiumVanadium150.94250.942
25.59%
20CaCalciumCalcium140.07840.078
20.13%
14SiSiliconSilicon128.08528.085
14.10%
Total199.100100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1993-032
  • Vanadomalayaiet

In other languages

German
IMA 1993-032 · Vanadomalayait
Italian
Vanadomalayaite

Classification

Strunz
10th ed.

9.AG.15

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.15VanadomalayaiteSpecies
Dana
8th ed.

52.04.03.03

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.03Titanite groupGroup
  • 52.04.03.03VanadomalayaiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1994Basso, R., Lucchetti, G., Zefiro, L., Palenzona, A. (1994) Vanadomalayaite, CaVOSiO4, a new mineral vanadium analog of titanite and malayaite. Neues Jahrbuch für Mineralogie - Monatshefte, 1994. 489-498
  2. 1995Jambor, J.L., Roberts, A.C. (1995) New mineral names. American Mineralogist: 80: 1073-1077.
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
