Waylandite

BiAl3(PO4)2(OH)6
IMA status
  • Approved
IMA symbol
Way
Discovered
1962
IMA approved
1962
Also known as
  • IMA1962-003
  • Waylandiet

Where it forms, where it's found

Geological setting

Secondary mineral replacing primary Bi minerals (rare); associated mineral concerns locality Ngusa, Kobokobo pegmatite, Rep. of Congo.

Restormel mine, Cornwall, England

Type locality
Wampewo Hill
  1. Busiro Co. (Bushiro Co.)
  2. Wakiso
  3. Central Region
  4. Uganda

0.5000°, 32.1667°

35recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colorless · white · pale blue · pale brown
Streak
White
Cleavage

fracture uneven when massive

Fracture
Irregular/Uneven
Density
4.08 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.748 – 1.774
Surface relief
High
Principal indices
nω 1.748 · nε 1.774
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 6.9744-6.9834 Å · c = 16.175-16.293 Å
Z
3
Twinning

often, cyclic

Type-locality form

Crystals to 0.5 mm; compact fine-grained powder in crusts and veinlets.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
38.49%
83BiBismuthBismuth1208.980208.980
35.91%
13AlAluminiumAluminium326.98280.946
13.91%
15PPhosphorusPhosphorus230.97461.948
10.65%
1HHydrogenHydrogen61.0086.048
1.04%
Total581.908100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1962-003
  • Waylandiet

In other languages

German
IMA 1962-003 · Waylandit
Italian
waylandite

Classification

Strunz
10th ed.

8.BL.13

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.13WaylanditeSpecies
Dana
8th ed.

41.05.12.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.12Waylandite GroupGroup
  • 41.05.12.01WaylanditeSpecies
CIM

17.6.14

  • 17Silicates Containing other AnionsClass
  • 17.6Silicates with phosphateGroup
  • 17.6.14WaylanditeSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1962von Knorring, O., Mrose, M.E. (1962) Westgrenite and waylandite, two new bismuth minerals from Uganda. Geological Society of America, Abstracts Annual Meetings 1962: 156A-157A.
  2. 1963Fleischer, Michael (1963) New Mineral Names. American Mineralogist, 48 (1-2) 209-217
  3. 1986Clark, A. M., Couper, A. G., Embrey, P. G., Fejer, E. E. (1986) Waylandite: new data, from an occurrence in Cornwall, with a note on ‘Agnesite’. Mineralogical Magazine, 50 (358) 731-733 doi:10.1180/minmag.1986.050.358.23 DOI: 10.1180/minmag.1986.050.358.23
  4. 1986Bayliss, P. (1986) X-Ray Powder Data for Nissonite and Waylandite. Powder Diffraction, 1 (4) 331-333 doi:10.1017/s0885715600012033DOI: 10.1017/s0885715600012033
  5. 1988Hawthorne, Frank C., Burke, Ernst A. J., Ercit, T. Scott, Grew, Edward S., Grice, Joel D., Jambor, John L., Puziewicz, Jacek, Roberts, Andrew C., Vanko, David A. (1988) New Mineral Names. American Mineralogist, 73 (1-2) 189-199
