Ammoniozippeite

(NH4)2[(UO2)2(SO4)O2] · H2O
IMA status
  • Approved
IMA symbol
Azip
IMA approved
2017
Also known as
  • Ammoniozippeiet
  • Ammoniozippéite
  • Ammoniozippeitt
  • +1 more

Where it forms, where it's found

Type locality
Burro Mine
  1. San Miguel County
  2. Colorado
  3. USA

38.0451°, -108.8896°

11recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow to yellowish orange
Streak
Pale yellow
Tenacity
brittle
Cleavage
Perfect

(010) and (001) perfect, (100) good

Fracture
Splintery
Density
4.433 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 87.1°
Refractive index
1.678 – 1.779
Surface relief
High
Principal indices
nα 1.678 · nβ 1.724 · nγ 1.779
Pleochroism
Visible

X colorless, Y orange yellow, and Z yellow orange (X ≪ Y < Z)

Dispersion
Weak
UV response
Dull green yellow under 405 nm laser light.
Michel-Lévy diagramhighlighted lineδ = 0.1010
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1010 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1010 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#49
Cell parameters
a = 8.7944(3) Å · b = 14.3296(7) Å · c = 17.1718(12) Å
Ratio a:b:c
1 : 1.629 : 1.953
Unit cell volume
2164 ų
Z
8
Morphology

Elongated on [100]

Type-locality form

Clusters of acicular to bladed crystals, to 2 mm.

Comment

Non-standard space-group seeting Ccmb

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
65.92%
8OOxygenOxygen1115.999175.989
24.37%
16SSulfurSulfur132.06032.060
4.44%
7NNitrogenNitrogen214.00728.014
3.88%
1HHydrogenHydrogen101.00810.080
1.39%
Total722.201100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ammoniozippeiet
  • Ammoniozippéite
  • Ammoniozippeitt
  • IMA2017-073

In other languages

German
Ammoniozippeit · IMA 2017-073

Classification

Strunz
10th ed.

7.EC.05

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.ECWith medium-sized and large cationsGroup
  • 7.EC.05AmmoniozippeiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2017Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2017) New minerals and nomenclature modifications approved in 2017, CNMNC Newsletter No 40. Mineralogical Magazine, 81 (6) 1577-1581 doi:10.1180/minmag.2017.081.096DOI: 10.1180/minmag.2017.081.096
  2. 2018Kampf, Anthony R., Plášil, Jakub, Olds, Travis A., Nash, Barbara P., Marty, Joe (2018) Ammoniozippeite, a New Uranyl Sulfate Mineral from the Blue Lizard Mine, San Juan County, Utah, and the Burro Mine, San Miguel County, Colorado, USA. The Canadian Mineralogist, 56 (3) 235-245 doi:10.3749/canmin.1800002 DOI: 10.3749/canmin.1800002
  3. 2020(2020) Ammoniozippeite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2023Sejkora, Jiří, Dolníček, Zdeněk, Plášil, Jakub (2023) Ammoniozippeite from the Jáchymov ore district, Krušné hory Mountains (Czech Republic) - description and Raman spectroscopy. Bulletin Mineralogie Petrologie, 31 (1) 1-9 doi:10.46861/bmp.31.001DOI: 10.46861/bmp.31.001
