Zippeite

K2[(UO2)4(SO4)2O2(OH)2](H2O)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Zip
Discovered
1845
Also known as
  • Basisches schwefelsaures Uranoxyd
  • Dauberit
  • Dauberita
  • +4 more

Where it forms, where it's found

Type locality
Eliáš Mine
  1. Jáchymov
  2. Karlovy Vary District
  3. Karlovy Vary Region
  4. Czech Republic

50.3744°, 12.8828°

174recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Golden yellow · light yellow · orange-yellow
Streak
White, yellow
Cleavage
Perfect

On (010) probable, perfect.

Density
4.88 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 59°
Refractive index
1.55 – 1.765
Surface relief
High
Principal indices
nα 1.55 – 1.655 · nβ 1.717 · nγ 1.765
Pleochroism
Visible

X = Nearly colourless Y = Light yellow to orange-yellow Z = Deep yellow to orange-yellow

Dispersion
strong
UV response
Green (UV).
Michel-Lévy diagramhighlighted lineδ = 0.1625
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1625 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1625 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2
Cell parameters
a = 8.7524(4) Å · b = 13.9197(7) Å · c = 17.6972(8) Å
Cell angles
β = 104.178(1) °
Ratio a:b:c
1 : 1.590 : 2.022
Z
2
Morphology

Crystals flattened (010). Commonly spindle- or lens-shaped; rhomboidal or lath-like at times. Occurs as delicate crusts, reniform or spheroidal aggregates comprised of microscopic crystals; powdery to earthy.

Twinning

Probable, observed in synthetic material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium4238.029952.116
63.96%
8OOxygenOxygen2415.999383.976
25.80%
19KPotassiumPotassium239.09878.196
5.25%
16SSulfurSulfur232.06064.120
4.31%
1HHydrogenHydrogen101.00810.080
0.68%
Total1488.488100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Basisches schwefelsaures Uranoxyd
  • Dauberit
  • Dauberita
  • Dauberite
  • Uranblüte
  • Uranblüthe
  • Uranoker

In other languages

French
Zippéite
German
IMA 1971-029a · Zippeit
Spanish
Zippeíta
Italian
Zippeite
Japanese
ジップ石 · ジッペ石 · チッペ石 · 鉱物
Chinese
水铀矾

Classification

Strunz
10th ed.

7.EC.05

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.ECWith medium-sized and large cationsGroup
  • 7.EC.05ZippeiteSpecies
Dana
8th ed.

31.10.04.01

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.10MiscellaneousType
  • 31.10.04Zippeite GroupGroup
  • 31.10.04.01ZippeiteSpecies
CIM

25.8.11

  • 25SulphatesClass
  • 25.8Sulphates of Sb, V, Cr and UGroup
  • 25.8.11ZippeiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1821John (1821) Chem. Unters.: 5 (as Basisches schwefelsaures Uranoxyd).
  2. 1824Zippe (1824) Verhl. Ges. Mus. Böhm.: 81 (as Uranblüthe).
  3. 1845Haidinger, W. (1845) Zweite Klasse: Geogenide. XI. Ordnung, Erze. VII. Uranerz. Zippeit.. in Handbuch der Bestimmenden Mineralogie, Bei Braumüller and Seidel (Wien): 506-511.
  4. 1845John (1845) Jb. Min.: 299 (as Basisches schwefelsaures Uranoxyd).
  5. 1845Haidinger (1845): 510 (as Zippeit).
