Magnesiozippeite

Mg(UO2)2(SO4)O2 · 3.5H2O
IMA status
  • Approved
IMA symbol
Mzip
Discovered
1976
Also known as
  • IMA2000-G
  • Magnesiozippeiet
  • Magnesium-zippeite
  • +1 more

Where it forms, where it's found

Type locality
Lucky Strike No. 2 Mine
  1. San Rafael Swell Mining District
  2. Emery County
  3. Utah
  4. USA

38.7556°, -110.9478°

16recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Intense yellow · orange · red brownish yellow.
Density
4.756 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.7 – 1.79
Surface relief
High
Principal indices
nα 1.7 · nβ 1.74 · nγ 1.79
Pleochroism
Visible

X = pale yellow; Y = yellow; Z = dark yellow.

Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0900
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]900 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation900 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 8.6514(4) Å · b = 14.1938(7) Å · c = 17.7211(9) Å
Cell angles
β = 104.131(1) °
Ratio a:b:c
1 : 1.641 : 2.048
Morphology

Earthy, granular/crystalline.

Comment

Data for synthetic sample. Natural crystals gave a cell with a halved volume and interlayer complex, which is distinctive from synthetics - there is an additional Mg-octahedron resulting in a infinite chain of polyhedra, instead of isolated dimers of Mg-octahedra in synthetic material (Plášil et al., 2013): a = 8.7005(5), b = 14.2541(6), c = 8.8433(5)Å, β = 104.408(5)°, V = 1062.24(9) Å3.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
63.02%
8OOxygenOxygen13.515.999215.987
28.59%
16SSulfurSulfur132.06032.060
4.24%
12MgMagnesiumMagnesium124.30524.305
3.22%
1HHydrogenHydrogen71.0087.056
0.93%
Total755.466100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2000-G
  • Magnesiozippeiet
  • Magnesium-zippeite
  • Magnesiumzippeit

In other languages

German
IMA 1971-007 · Magnesiozippeit
Italian
Magnesio-zippeite · Magnesiozippeite
Chinese
水镁铀矾

Classification

Strunz
10th ed.

7.EC.05

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.ECWith medium-sized and large cationsGroup
  • 7.EC.05MagnesiozippeiteSpecies
Dana
8th ed.

31.10.04.03

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.10MiscellaneousType
  • 31.10.04Zippeite GroupGroup
  • 31.10.04.03MagnesiozippeiteSpecies
CIM

25.8.13

  • 25SulphatesClass
  • 25.8Sulphates of Sb, V, Cr and UGroup
  • 25.8.13MagnesiozippeiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1976Frondel, C., Ito, J., Honea, R.M., Weeks, A.M. (1976) Mineralogy of the zippeite group. The Canadian Mineralogist: 14: 429-436.
  2. 1982Spitsyn, V., Kovba, L., Tabachenko, V., Tabachenko, N., Mikhaylov, Y. (1982) To the investigation of basic uranyl salts and polyuranates. Abstract Bulletin of the Institute of Paper Chemistry: 52: 711-714.
  3. 1997Ondruš, P., Veselovský, F., Hloušek, J., Skála, R., Vavřín, I., Frýda, J., Čejka, J., Gabašová, A. (1997) Secondary minerals of the Jáchymov (Joachimsthal) ore district. Journal of the Czech Geological Society, 42 (4). 3-69
  4. 1997Ondruš, P., Veselovský, F., Skála, R., Cisařová, I., Hloušek, J., Frýda, J., Vavřín, I., Čejka, J., Gabašová, A. (1997) New naturally occurring phases of secondary origin from Jáchymov (Joachimsthal) Journal of the Czech Geological Society, 42 (4) 77-108
  5. 2003Brugger, J., Burns, Peter C., Meisser, N. (2003) Contribution to the mineralogy of acid drainage of Uranium minerals: Marecottite and the zippeite-group. American Mineralogist, 88 (4) 676-685 doi:10.2138/am-2003-0421 DOI: 10.2138/am-2003-0421
