Arupite

Ni3(PO4)2 · 8H2O
IMA status
  • Approved
IMA symbol
Arp
Discovered
1990
Also known as
  • Arupiet
  • Arupitt
  • IMA1988-008

Where it forms, where it's found

Geological setting

Weathered meteorite.

Type locality
Santa Catharina meteorite
  1. Morro do Rócio
  2. São Francisco do Sul
  3. Santa Catarina
  4. Brazil

-26.2167°, -48.6000°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Blue to light blue
Streak
Light blue
Cleavage

Probably the same as other members of the vivianite group, but not mentioned.

Density
2.85 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 60 – 70° · 2V calc = 78°
Refractive index
1.632 – 1.68
Surface relief
High
Principal indices
nα 1.632 · nβ 1.65 · nγ 1.680
Birefringence
0.048
Pleochroism
Visible

X = blue, Z = colorless

Dispersion
r < v strong
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0480
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]480 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation480 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#11
Cell parameters
a = 9.889 Å · b = 13.225 Å · c = 4.645 Å
Cell angles
β = 102.41 °
Ratio a:b:c
1 : 1.337 : 0.470
Z
2
Type-locality form

Short prismatic blue crystals to 5 microns.

Comment

I2/m

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
50.18%
28NiNickelNickel358.693176.079
34.52%
15PPhosphorusPhosphorus230.97461.948
12.14%
1HHydrogenHydrogen161.00816.128
3.16%
Total510.139100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe

Synonyms

  • Arupiet
  • Arupitt
  • IMA1988-008

In other languages

German
Arupit · IMA 1988-008
Italian
Arupite
Chinese
水磷镍石

Classification

Strunz
10th ed.

8.CE.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.40ArupiteSpecies
Dana
8th ed.

40.03.06.08

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.03A3(XO4)2·xH2OType
  • 40.03.06Vivianite GroupGroup
  • 40.03.06.08ArupiteSpecies
CIM

19.15.1

  • 19PhosphatesClass
  • 19.15Phosphates of NiGroup
  • 19.15.1ArupiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1990Jambor, John L.; Puziewicz, Jacek (1990) New Mineral Names. American Mineralogist, 75 (9-10). 1209-1216
  2. 1990Buchwald, V.F. (1990) A new mineral, arupite, Ni3(PO4)2·8H2O, the nickel analogue of vivianite. Neues Jahrbuch für Mineralogie, Monatshefte,, 76-80
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2007(2007) Arupite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2008Shouwen, J., Wang, D., Gao, X., Wen, X., Zhou, J. (2008) Poly[octaaquadi-μ-phosphato-tri-nickel(II)]. Acta Crystallographica, E64, m259-m259.
