Cabrerite

NiMg2(AsO4)2·8H2O
IMA status
  • Approved
IMA symbol
Cabr
IMA approved
2024
Also known as
  • Cabreriet
  • IMA2023-123

Where it forms, where it's found

Geological setting

Oxygenated Ni Co arsenides

Type locality
Nickel mine (Bell Nickel
  1. Cottonwood Canyon Nickel Mine
  2. London and Liverpool Mines)
  3. Bolivia
  4. Cottonwood Canyon
  5. Churchill County
  6. Nevada
  7. USA

39.9902°, -117.9077°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Green · pale greenish · pale pinkish
Streak
pale green to white
Tenacity
sectile
Cleavage
Perfect

three cleavages: perfect on (010), fair on (100) and poor on (102).

Fracture
Irregular/Uneven · Step-Like
Density
2.93 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 82°
Refractive index
1.609 – 1.667
Surface relief
Moderate
Principal indices
nα 1.609 · nβ 1.633 · nγ 1.667
Pleochroism
Non-pleochroic
Dispersion
slight r < v dispersion
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0580
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]580 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation580 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 10.205(1) Å · b = 13.377(1) Å · c = 4.7382(4) Å
Cell angles
β = 105.057(7) °
Ratio a:b:c
1 : 1.311 : 0.464
Z
2
Twinning

None

Type-locality form

divergent groups of green blades up to 1 mm long. Blades are elongated and striated parallel to [001],

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
48.37%
33AsArsenicArsenic274.922149.844
28.31%
28NiNickelNickel158.69358.693
11.09%
12MgMagnesiumMagnesium224.30548.610
9.18%
1HHydrogenHydrogen161.00816.128
3.05%
Total529.259100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Cabreriet
  • IMA2023-123

In other languages

German
Cabrerit

Classification

Strunz
10th ed.

8.CE.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.40CabreriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. Kampf, A.R., Adams, P.M. and Ma, C. (2024) Cabrerite, IMA 2023-123. CNMNC Newsletter 79, Mineralogical Magazine, 88
  2. Dillen, Rik (2024) Cabreriet... een nieuw mineraal met een niet-nieuwe mineraalnaam. Geonieuws: 49(10): 261-264.
  3. 1996Wildner, Manfred, Giester, Gerald, Lengauer, Christian L., Mccammon, Catherine A. (1996) Structure and crystal chemistry of vivianite-type compounds: Crystal structures of erythrite and annabergite with a Mössbauer study of erythrite. European Journal of Mineralogy, 8 (1) 187-192 doi:10.1127/ejm/8/1/0187DOI: 10.1127/ejm/8/1/0187
  4. 1996Rojo, J.M.; Mesa, J.L.; Pizarro, J.L.; Lezama, L.; Arriortua, M.I.; Rojo, T. (1996) Spectroscopic and magnetic study of the (Mg,M)3(AsO4)2·8H2O (M = Ni2+, Co2+) arsenates. Materials Research Bulletin, 31 (8). 925-934 doi:10.1016/s0025-5408(96)00088-8DOI: 10.1016/s0025-5408(96)00088-8
  5. 2025Kampf, Anthony R., Adams, Paul M., Ma, Chi (2025) Cabrerite, NiMg2(AsO4)2·8H2O, a new old mineral – the ordered intermediate between annabergite and hörnesite. American Mineralogist, 110 (4). 643-649 doi:10.2138/am-2024-9498DOI: 10.2138/am-2024-9498
