Bafertisite

Ba2Fe2+4Ti2(Si2O7)2O2(OH)2F2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bft
Discovered
1959
Also known as
  • Bafertisiet
  • Bafertisitt

Where it forms, where it's found

Geological setting

Hydrothermal veins.

Type locality
Bayan Obo deposit
  1. Bayan Obo mining district
  2. Baotou City
  3. Inner Mongolia
  4. China

41.7958°, 109.9694°

20recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Red · yellowish-red · light brown
Streak
White
Cleavage
Distinct/Good

One distinct and one poor cleavage.

Density
3.96 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 54 – 86° · 2V calc = 82 – 88°
Refractive index
1.786 – 1.862
Surface relief
Very high
Principal indices
nα 1.786 – 1.808 · nβ 1.813 – 1.835 · nγ 1.852 – 1.862
Pleochroism
Visible

X = yellow red; Z = pale yellow.

Dispersion
r << v
Notes

Absorption: X > Z.

Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 10.665(2) Å · b = 13.743(2) Å · c = 11.721(3) Å
Cell angles
α = 90.30(4) ° · β = 112.27(2) ° · γ = 90.00(3) °
Ratio a:b:c
1 : 1.289 : 1.099
Unit cell volume
1589.8 ų
Type-locality form

Aggregates of acicular crystals 1.5 cm long.

Comment

Space group C1

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
27.85%
56BaBariumBarium2137.327274.654
26.56%
26FeIronIron455.845223.380
21.60%
14SiSiliconSilicon428.085112.340
10.86%
22TiTitaniumTitanium247.86795.734
9.26%
9FFluorineFluorine218.99837.996
3.67%
1HHydrogenHydrogen21.0082.016
0.20%
Total1034.102100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Nb
  • Mg
  • Ca
  • K
  • Na
  • F
  • Cl

Synonyms

  • Bafertisiet
  • Bafertisitt

In other languages

German
Bafertisit
Italian
Bafertisite

Classification

Strunz
10th ed.

9.BE.55

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.55BafertisiteSpecies
Dana
8th ed.

56.02.6b.01

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.6b— unnamed intermediate level —Group
  • 56.02.6b.01BafertisiteSpecies
CIM

14.9.17

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.17BafertisiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1959Peng Ch'i-jui (1959) The discovery of several new minerals of rare elements. Ti-chih K'o-hsueh, 10, 289. (in Chinese)
  2. 1959Semenov, E. I., and Chang Pei-Shan (1959) New mineral - Bafertisite. Science Record (Beijing), 3(12), 652-655 (in Russian).
  3. 1960Fleischer, M.; Chao, E.C.T. (1960) New mineral names. American Mineralogist, 45 (5-6). 753-756
  4. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (11-12). 1313-1317
  5. 1963Guan, Ya.S., Simonov, V.I., Belov, N.V. (1963) The crystal structure of bafertisite BaFe2TiO[Si2O7](OH)2. Doklady Akademii Nauk SSSR, 149, 1416-1419.
