Yoshimuraite

Ba4Mn2+4Ti2(Si2O7)2(PO4)2O2(OH)2
IMA status
  • Approved
IMA symbol
Ysh
Discovered
1959
Also known as
  • Yoshimuraiet

Where it forms, where it's found

Geological setting

In the border facies of an alkalic pegmatite cutting a stratiform manganese deposit.

Type locality
Noda-Tamagawa mine
  1. Noda
  2. Kunohe-gun
  3. Iwate Prefecture
  4. Japan

40.0733°, 141.8083°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Orange-brown · red · dark brown
Tenacity
brittle
Cleavage

[010] Perfect, [101] Distinct, [101] Distinct

Density
4.13 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85 – 90° · 2V calc = 72°
Refractive index
1.763 – 1.785
Surface relief
High
Principal indices
nα 1.763 · nβ 1.777 · nγ 1.785
Pleochroism

X = bright yellow Y = orange-brown Z = brown

Dispersion
very strong
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7(1) Å · b = 14.71(2) Å · c = 5.39(1) Å
Cell angles
α = 93.52(2) ° · β = 90.2(2) ° · γ = 95.3(2) °
Ratio a:b:c
1 : 2.101 : 0.770
Z
2
Twinning

Polysynthetic on (010), common.

Type-locality form

Platy to bladed or tabular crystals, to 5 cm; in stellate groups and platy masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium4137.327549.308
37.70%
8OOxygenOxygen2615.999415.974
28.55%
25MnManganeseManganese454.938219.752
15.08%
14SiSiliconSilicon428.085112.340
7.71%
22TiTitaniumTitanium247.86795.734
6.57%
15PPhosphorusPhosphorus230.97461.948
4.25%
1HHydrogenHydrogen21.0082.016
0.14%
Total1457.072100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Zn
  • Mg
  • Ca
  • Na
  • K
  • H2O

Synonyms

  • Yoshimuraiet

In other languages

German
Yoshimurait
Italian
Yoshimuraite
Japanese
吉村石
Chinese
硅钛锰钡石

Classification

Strunz
10th ed.

9.BE.42

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.42YoshimuraiteSpecies
Dana
8th ed.

58.02.06.01

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.06Yoshimuraite and related speciesGroup
  • 58.02.06.01YoshimuraiteSpecies
CIM

17.10.26

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.26YoshimuraiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1959Watanabe, Takeo (1959) The minerals of the Noda-Tamagawa Mine, Iwate Prefecture, Japan. I. Notes on Geology and Parageneses of Minerals. Mineralogical Journal, 2 (6). 408-421 doi:10.2465/minerj1953.2.408 DOI: 10.2465/minerj1953.2.408
  2. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (3-4). 476-480
  3. 1961WATANABE, TAKEO, TAKÉUCHI, YOSHIO, ITO, JUN (1961) The minerals of the Noda-Tamagawa mine, Iwaté Prefecture, Japan. III. Yoshimuraite, a new barium-titanium-manganese silicate mineral. Mineralogical Journal, 3 (3). 156-167 doi:10.2465/minerj1953.3.156 DOI: 10.2465/minerj1953.3.156
  4. 1961Fleischer, M. (1961) New mineral names. American Mineralogist, 46 (11-12). 1513-1520
  5. 1966Hirowatari, F. and Isono, K. (1966) Yoshimuraite from the manganese ore deposits of Taguchi mine, Aichi Pref., Japan. Journal of the Mineralogical Society of Japan: 6: 230-243 (in Japanese).
