Bismutocolumbite

BiNbO4
IMA status
  • Approved
IMA symbol
Bclb
Also known as
  • Bismutocolumbiet
  • IMA1991-003

Where it forms, where it's found

Geological setting

In a pegmatite

Type locality
Danburitovaya pegmatite vein
  1. Malkhan pegmatite field
  2. Krasnyi Chikoy
  3. Krasnochikoysky District
  4. Zabaykalsky Krai
  5. Russia
2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Black · brown in transmitted light
Streak
Brown to pale yellow
Tenacity
brittle
Cleavage
Perfect

on (010)

Fracture
Conchoidal
Density
7.17 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 85°
Refractive index
2.38 – 2.47
Surface relief
Very high
Principal indices
nα 2.38 · nβ 2.42 · nγ 2.47
Dispersion
Relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0900
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]900 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation900 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.992 Å · b = 5.677 Å · c = 11.731 Å
Ratio a:b:c
1 : 1.137 : 2.350
Z
4
Type-locality form

Prismatic crystals to 2 mm, striated parallel to their elongation

Comment

Space Group: Pcnn

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth1208.980208.980
57.12%
41NbNiobiumNiobium192.90692.906
25.39%
8OOxygenOxygen415.99963.996
17.49%
Total365.882100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ta
  • Pb
  • Sb
  • Sn
  • Ti

Synonyms

  • Bismutocolumbiet
  • IMA1991-003

In other languages

German
Bismutocolumbit · IMA 1991-003
Italian
Bismutocolumbite
Chinese
铋铌铁矿

Classification

Strunz
10th ed.

4.DE.30

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DEWith medium-sized cations; with various polyhedraGroup
  • 4.DE.30BismutocolumbiteSpecies
Dana
8th ed.

08.01.06.04

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.01ABO4Type
  • 08.01.06Stibiocolumbite GroupGroup
  • 08.01.06.04BismutocolumbiteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1992Peretazhko, I. S., Zagorskiy, V. E., Sapozhnikov, A. N., Bobrov, Y. D. and Rakcheev, A. D. (1992) Bismutocolumbite Bi(Nb,Ta)O4 - a new mineral from miarolitic pegmatites. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva 121(3), 130-134 (in Russian).
  2. 1994Jambor, John L., Roberts, Andrew C., Puziewicz, Jacek (1994) New Mineral Names. American Mineralogist, 79 (5-6) 570-574
  3. 1994Mineralogical Abstracts (1994), 45, 111 (abstract).
  4. 1997Anthony, J. W. et al. (1997) Handbook of Mineralogy, Vol. 3, 62.
  5. 2002Zubkova, N. V., Puscharovsky, D. Y., Giester, G., Smolin, A. S., Tillmanns, E., Brandstätter, F., Hammer, V., Peretazhko, I. S., Sapozhnikov, A. N. and Kashaev, A. A. (2002) Bismutocolumbite, Bi(Nb0.79Ta0.21)O4, stibiocolumbite, Sb(Nb0.67Ta0.33)O4, and their structural relation to the other ABO4 minerals with stibiotantalite (SbTaO4) structure. Neues Jahrbuch für Mineralogie, Monatshefte: 145-159.
