Stibiocolumbite

SbNbO4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sclb
Discovered
1915
Also known as
  • Stibiocolumbiet
  • Stibiocolumbita

Where it forms, where it's found

Type locality
Himalaya Mine
  1. Gem Hill
  2. Mesa Grande Mining District
  3. San Diego County
  4. California
  5. USA

33.2119°, -116.7978°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark brown to light yellowish brown · reddish yellow · reddish brown · greenish yellow
Streak
Light yellow, yellow-brown
Tenacity
brittle
Cleavage
Distinct/Good

(010) distinct; (100) indistinct

Fracture
Sub-Conchoidal
Density
5.68 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 73° · 2V calc = 74°
Refractive index
2.3977 – 2.4588
Surface relief
Very high
Principal indices
nα 2.3977 · nβ 2.419 · nγ 2.4588
Dispersion
r < v
Michel-Lévy diagramhighlighted lineδ = 0.0611
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]611 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation611 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.929 Å · b = 11.797 Å · c = 5.559 Å
Ratio a:b:c
1 : 2.393 : 1.128
Z
4
Morphology

Prismatic [001]. (010) and (110) striated parallel to [001]. The crystals infreqently exhibit morphological evidence of hemimorphism.

Twinning

About [010] with composition plane (001), commonly an irregular junction, or polysynthetic

Comment

Space Group: P c21n (synthetic SbNbO4).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
43.69%
41NbNiobiumNiobium192.90692.906
33.34%
8OOxygenOxygen415.99963.996
22.97%
Total278.662100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ta

Synonyms

  • Stibiocolumbiet
  • Stibiocolumbita

In other languages

German
Stibiocolumbit
Italian
Stibiocolumbite
Chinese
铌锑矿

Classification

Strunz
10th ed.

4.DE.30

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DEWith medium-sized cations; with various polyhedraGroup
  • 4.DE.30StibiocolumbiteSpecies
Dana
8th ed.

08.01.06.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.01ABO4Type
  • 08.01.06Stibiocolumbite GroupGroup
  • 08.01.06.01StibiocolumbiteSpecies
CIM

18.1.27

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.27StibiocolumbiteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1906Penfield, S.L., Ford, W.E. (1906) On stibiotantalite. American Journal of Science, 4th. series: 22: 61-77.
  2. 1915Schaller (1915) private contr. in Dana: 74.
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1963Roth, R. S., Waring, J. L. (1963) Synthesis and stability of bismutotantalite, stibiotantalite and chemically similar ABO4 compounds. American Mineralogist, 48 (11-12) 1348-1356
  5. 1981Foord, E.E. (1981) Bismuthian stibiocolumbite-tantalite and other minerals from the Little Three mine, Ramona, California: Mineral Society of America – Friends of Mineralogy, symposium abstracts.
