Stibiotantalite

Sb3+TaO4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sttl
Discovered
1893
Also known as
  • Stibiotantalita

Where it forms, where it's found

Geological setting

Alluvial

Uncommon accessory mineral in complex granitic pegmatites.

Type locality
Greenbushes Sn placers
  1. Greenbushes Mine
  2. Bridgetown-Greenbushes Shire
  3. Western Australia
  4. Australia

-33.8543°, 116.0610°

58recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark brown to light yellowish brown · reddish yellow · reddish brown · greenish yellow
Streak
Light yellow, yellow-brown
Tenacity
brittle
Cleavage
Distinct/Good

(001) distinct; (100) indistinct.

Fracture
Sub-Conchoidal
Density
5.98 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75° · 2V calc = 76°
Refractive index
2.3742 – 2.4568
Surface relief
Very high
Principal indices
nα 2.3742 · nβ 2.4039 · nγ 2.4568
Dispersion
relatively strong r<v
Extinction
X = a; Y = b; Z = c
Michel-Lévy diagramhighlighted lineδ = 0.0826
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]826 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation826 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.911 Å · b = 11.814 Å · c = 5.535 Å
Ratio a:b:c
1 : 2.406 : 1.127
Z
4
Morphology

Prismatic [001]. (010) and (110) striated parallel to [001]. The crystals infreqently exhibit morphological evidence of hemimorphism.

Twinning

Polysynthetic twinning with twin axis [010] and composition plane (001); also individuals irregularly intergrown.

Type-locality form

Waterworn pebble

Comment

Space Group: P c21n (synthetic SbTaO4).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
73TaTantalumTantalum1180.948180.948
49.35%
51SbAntimonyAntimony1121.760121.760
33.20%
8OOxygenOxygen415.99963.996
17.45%
Total366.704100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Nb

Synonyms

  • Stibiotantalita

In other languages

German
Stibiotantalit
Spanish
Estibiotantalita
Italian
Stibiotantalite
Japanese
スティビオタンタライト

Classification

Strunz
10th ed.

4.DE.30

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DEWith medium-sized cations; with various polyhedraGroup
  • 4.DE.30StibiotantaliteSpecies
Dana
8th ed.

08.01.06.02

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.01ABO4Type
  • 08.01.06Stibiocolumbite GroupGroup
  • 08.01.06.02StibiotantaliteSpecies
CIM

18.1.28

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.28StibiotantaliteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1893Goyder, G.A. (1893) Stibiotantalite: a new mineral. in Proceedings of the Chemical Society (London): 9(127): 171-197 (184).
  2. 1893Goyder, G.A. (1893) On a new mineral (stibiotantalite). Transactions and Proceedings and Report of the Royal Society of South Australia: 17: 127-128.
  3. 1893Goyder, G.A. (1893) Stibiotantalite. A new mineral. Journal Chemical Society Transactions: 63: 1076-1079.
  4. 1906Penfield, Samuel Lewis & William Ebenezer Ford (1906) On stibiotantalite. American Journal of Science, 4th. series: 22: 61-77.
  5. 1906Zeitschrift für Kristallographie, Band 43: 334-350 (1906).
