Bismutotantalite

BiTaO4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bttl
Discovered
1929
Also known as
  • Bismutotantaliet
  • Ugandit
  • Ugandita

Where it forms, where it's found

Geological setting

Granite pegmatite

In pegmatites; in alluvial placers

Type locality
Gamba Hill
  1. Busiro Co. (Bushiro Co.)
  2. Wakiso
  3. Central Region
  4. Uganda
17recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Light brown to pitch-black · very thin splinters are light smoke-grey to colourless in transmitted light
Streak
Yellow, yellow-brown to black
Cleavage
Distinct/Good

On (010), distinct on (101) and (100).

Fracture
Sub-Conchoidal
Density
8.15 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80° · 2V calc = 78°
Refractive index
2.388 – 2.428
Surface relief
Very high
Principal indices
nα 2.388 – 2.395 · nβ 2.403 – 2.408 · nγ 2.426 – 2.428
Dispersion
r < v
Notes

The mineral is isotropic when metamict

Michel-Lévy diagramhighlighted lineδ = 0.0355
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]355 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation355 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.99(1) Å · b = 11.85(4) Å · c = 5.68(2) Å
Ratio a:b:c
1 : 2.375 : 1.138
Z
4
Morphology

Stout crystals, prismatic on [001], to 10 cm; commonly irregular or misshapen; as stream-rounded pebbles in placers.

Type-locality form

Large (to 10x6x6 cm) misshapen crystals up to several pounds in weight.

Comment

may be metamict. Point Group: 2/m 2/m 2/m or mm2; Space Group: P cmn or P cn21.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth1208.980208.980
46.04%
73TaTantalumTantalum1180.948180.948
39.86%
8OOxygenOxygen415.99963.996
14.10%
Total453.924100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mn
  • Sb
  • Si
  • Zn

Synonyms

  • Bismutotantaliet
  • Ugandit
  • Ugandita

In other languages

German
Bismutotantalit
Italian
Bismutotantalite

Classification

Strunz
10th ed.

4.DE.30

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DEWith medium-sized cations; with various polyhedraGroup
  • 4.DE.30BismutotantaliteSpecies
Dana
8th ed.

08.01.06.03

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.01ABO4Type
  • 08.01.06Stibiocolumbite GroupGroup
  • 08.01.06.03BismutotantaliteSpecies
CIM

18.1.34

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.34BismutotantaliteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1929Gordon, S.G., Smith, W.C. (1929) Proceedings of Societies: Philadelphia Mineralogical Society; Mineralogical Society of Great Britain and Ireland. American Mineralogist: 14: 311-312.
  2. 1929Wayland, E. J., Spencer, L. J. (1929) Bismutotantalite, a new mineral, from Uganda. Mineralogical Magazine and Journal of the Mineralogical Society, 22 (127) 185-192 doi:10.1180/minmag.1929.022.127.04 DOI: 10.1180/minmag.1929.022.127.04
  3. 1930Foshag, W.F. (1930) New mineral names. American Mineralogist, 15 (5). 201-204
  4. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  5. 1957Hurlbut, Cornelius S. (1957) Bismutotantalite from Brazil. American Mineralogist, 42 (3-4) 178-183
