Clinocervantite

Sb3+Sb5+O4
IMA status
  • Approved
IMA symbol
Ccvn
Also known as
  • Clinocervantiet
  • Clinocervantit
  • IMA1997-017

Where it forms, where it's found

Type locality
Tafone mine (Valle del Tafone mining area)
  1. Manciano
  2. Grosseto Province
  3. Tuscany
  4. Italy

42.4799°, 11.5564°

3recorded occurrences
Source · OpenStreetMap

Physical

Lustre
Vitreous
Transparency
Transparent
Colour
Colorless
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
6.72 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.72 – 2.1
Surface relief
Very high
Principal indices
nα 1.72 · nγ 2.10
Dispersion
r < v moderate
UV response
Does not fluoresce
Michel-Lévy diagramhighlighted lineδ = 0.3800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]3800 nm7th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation3800 nm
Order7th order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 12.061(1) Å · b = 4.836(1) Å · c = 5.383(1) Å
Cell angles
β = 104.60(4) °
Ratio a:b:c
1 : 0.401 : 0.446
Z
4
Morphology

Elongated along [001]. Dominant prism (110) combined with lesser (122) and (211) prisms.

Twinning

Twinned with composition plane (100)

Type-locality form

Aggregates of prismatic crystals. The crystals do not exceed 0.2 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony2121.760243.520
79.19%
8OOxygenOxygen415.99963.996
20.81%
Total307.516100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Clinocervantiet
  • Clinocervantit
  • IMA1997-017

In other languages

German
IMA 1997-017 · Klinocervantit
Italian
Clinocervantite

Classification

Strunz
10th ed.

4.DE.30

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DEWith medium-sized cations; with various polyhedraGroup
  • 4.DE.30ClinocervantiteSpecies

Group, growth & confusion

In the same group
5 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1988Amador, J., Gutierrez Puebla, E., Monge, M. A., Rasines, I., Ruiz Valero, C. (1988) Diantimony tetraoxides revisited. Inorganic Chemistry, 27 (8) 1367-1370 doi:10.1021/ic00281a011DOI: 10.1021/ic00281a011
  2. 1989Golunski, Stanislaw E., Jackson, David (1989) Antimony Oxides: A guide to phase changes during catalyst preparation. Applied Catalysis, 48 (1). 123-135 doi:10.1016/s0166-9834(00)80270-5DOI: 10.1016/s0166-9834(00)80270-5
  3. 1999Basso, Riccardo, Lucchetti, Gabriella, Zefiro, Liviο, Palenzona, Andrea (1999) Clinocervantite, ß-Sb2O4, the natural monoclinic polymorph of cervantite from the Cetine mine, Siena, Italy. European Journal of Mineralogy, 11 (1) 95-100 doi:10.1127/ejm/11/1/0095 DOI: 10.1127/ejm/11/1/0095
  4. 2017Menchetti, Silvio, Batoni, Massimo (2017) Clinocervantite. Alle Cetine il primo ritrovamento su matrice naturale [Clinocervantite. The first discovery on a natural matrix in Cetina]. Micro, 15 (2). 96-103
  5. 2021(2021) Clinocervantite. Handbook of Mineralogy. Mineralogical Society of America
