Bjarebyite

BaMn2+2Al2(PO4)3(OH)3
IMA status
  • Approved
IMA symbol
Bj
Discovered
1973
Also known as
  • Bjarebyiet
  • IMA1972-022

Where it forms, where it's found

Geological setting

Late stage reaction product of triphylite and amblygonite in complex granite pegmatites.

Type locality
Palermo No. 1 Mine
  1. Groton
  2. Grafton County
  3. New Hampshire
  4. USA

43.7513°, -71.8896°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Emerald green
Streak
White
Cleavage
Perfect

(010) and (100)

Density
3.90 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 35° · 2V calc = 50°
Refractive index
1.692 – 1.749
Surface relief
High
Principal indices
nα 1.692 – 1.724 · nβ 1.695 – 1.727 · nγ 1.710 – 1.749
Pleochroism
Visible

Weak, grayish tan to pale yellow-green; also strong, X = colorless to pale brownish yellow; Y = brownish green; Z = apple-green or olive-green.

Dispersion
weak to distinct
Extinction
Y = b, Z ∧ c = 7–8°.
Michel-Lévy diagramhighlighted lineδ = 0.0215
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]215 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation215 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 8.930(14) Å · b = 12.073(24) Å · c = 4.917(9) Å
Cell angles
β = 100.15(13) °
Ratio a:b:c
1 : 1.352 : 0.551
Z
2
Type-locality form

As multiply-faceted, steeply-terminated, spearhead-shaped crystals, to 3 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
37.67%
56BaBariumBarium1137.327137.327
21.55%
25MnManganeseManganese254.938109.876
17.25%
15PPhosphorusPhosphorus330.97492.922
14.59%
13AlAluminiumAluminium226.98253.964
8.47%
1HHydrogenHydrogen31.0083.024
0.47%
Total637.098100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bjarebyiet
  • IMA1972-022

In other languages

French
bjarébyite
German
Bjarebyit · IMA 1972-022
Italian
Bjarebyite
Chinese
磷铝锰钡石

Classification

Strunz
10th ed.

8.BH.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.20BjarebyiteSpecies
Dana
8th ed.

41.09.01.03

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.09(AB)5(XO4)3ZqType
  • 41.09.01Kulanite GroupGroup
  • 41.09.01.03BjarebyiteSpecies
CIM

19.5.13

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.13BjarebyiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1973Moore, Paul B., Lund, Dennis H., Keester, Kenneth L. (1973) Bjarebyite, (Ba,Sr)(Mn,Fe,Mg)2Al2(OH)3(PO4)3, a New Species. The Mineralogical Record, 4 (6) 282-285
  2. 1974Moore, Paul Brian, Araki, Takaharu (1974) Bjarebyite, Ba(Mn,Fe)2+2Al2(OH)3[PO4]3: Its atomic arrangement. American Mineralogist, 59 (5-6) 567-572
  3. 1974Fleischer, Michael (1974) New mineral names. American Mineralogist, 59 (7-8). 873-875
  4. 1975von Knorring, O., Fransolet, A.-M. (1975) An occurrence of bjarebyite in the Buranga pegmatite, Rwanda. Neues Jahrbuch für Mineralogie - Monatshefte, 1975. 9-18
  5. 1983Thomasson, R. (1983) M.Sc. thesis, Lund University, 30 pp.
