Kulanite

BaFe2+2Al2(PO4)3(OH)3
IMA status
  • Approved
IMA symbol
Kul
Discovered
1976
Also known as
  • IMA1975-012
  • Kulaniet

Where it forms, where it's found

Geological setting

Fractures in the "ironstone" beds (a sideritic iron-formation). Low temperature.

Type locality
Crosscut Creek
  1. Kulan Camp (Area A
  2. Area 1)
  3. Rapid Creek
  4. Dawson mining district
  5. Yukon
  6. Canada

68.5627°, -136.7982°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Blue · blue-green · green
Streak
Greenish white
Cleavage
Imperfect/Fair

Fair to good, parallel to (010) and (100)

Density
3.91 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 32° · 2V calc = 38°
Refractive index
1.703 – 1.723
Surface relief
High
Principal indices
nα 1.703 · nβ 1.705 · nγ 1.723
Pleochroism
Strong

α = brownish green, β = green, and γ = very pale brown

Dispersion
Very strong r>>v (type description)
Extinction
Absorption: α ≅ β >> γ
UV response
None
Notes

b ≅ β, c Λ γ = -8 deg. One optic axis is almost normal to (101).

Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 9.0518(2) Å · b = 12.1362(3) Å · c = 4.9411(1) Å
Cell angles
β = 100.443(2) °
Ratio a:b:c
1 : 1.341 : 0.546
Z
2
Morphology

Tabular parallel to (101). Forms include (001), (100), (120), (110), (011), (031), (101), (301), (111), (121), (131), and (161).

Type-locality form

Green to blue plates to 3x3x0.5 mm. Commonly arranged in rosette like aggregates.

Comment

~ 297 K

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
37.56%
56BaBariumBarium1137.327137.327
21.50%
26FeIronIron255.845111.690
17.48%
15PPhosphorusPhosphorus330.97492.922
14.54%
13AlAluminiumAluminium226.98253.964
8.45%
1HHydrogenHydrogen31.0083.024
0.47%
Total638.912100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1975-012
  • Kulaniet

In other languages

French
Kulanite
German
IMA 1975-012 · Kulanit
Italian
Kulanite

Classification

Strunz
10th ed.

8.BH.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.20KulaniteSpecies
Dana
8th ed.

41.09.01.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.09(AB)5(XO4)3ZqType
  • 41.09.01Kulanite GroupGroup
  • 41.09.01.01KulaniteSpecies
CIM

19.5.14

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.14KulaniteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1976Mandarino, J. A.; Sturman, B. D. (1976) Kulanite, a new barium iron aluminum phosphate from the Yukon Territory, Canada. The Canadian Mineralogist, 14 (2). 127-131
  2. 1986Yang, Y., Ni, Y., Guo, Y., Zhang, Y., Liu, J. (1986) First discovery of kulanite in China. Acta Petrologica et Mineralogica: 5(2): 119-127 + pl.I (in Chinese with English abstract).
  3. 1986IMA meeting (1986) Program & Abstract.
  4. 1990Jambor, John L., Grew, Edward S. (1990) New Mineral Names. American Mineralogist, 75 (1-2) 240-246
  5. 1992Robinson, George W., Van Velthuizen, Jerry, Ansell, H. Gary, Sturman, B. Darko (1992) Mineralogy of the Rapid Creek and Big Fish River Area, Yukon Territory. The Mineralogical Record, 23 (4) 1-47
