Chongite

Ca3Mg2(AsO4)2(AsO3OH)2 · 4H2O
IMA status
  • Approved
IMA symbol
Cng
IMA approved
2015
Also known as
  • Chongiet
  • IMA2015-039

Where it forms, where it's found

Geological setting

Veins rich in secondary arsenic and copper minerals that intersect metamorphosed marine shales and lavas. Formed from the oxidation of native arsenic and other As-bearing primary phases, followed by later alteration by saline fluids derived from evaporating meteoric water under hyperarid conditions.

Type locality
Torrecillas mine
  1. Iquique
  2. Iquique Province
  3. Tarapacá
  4. Chile

-20.9767°, -70.1419°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Streak
white
Tenacity
brittle
Cleavage
Distinct/Good

on (100)

Fracture
Conchoidal
Density
3.09 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 76.9° · 2V calc = 76.9°
Refractive index
1.612 – 1.635
Surface relief
Moderate
Principal indices
nα 1.612 · nβ 1.626 · nγ 1.635
Pleochroism
Non-pleochroic
Dispersion
r & lt; v, distinct
Michel-Lévy diagramhighlighted lineδ = 0.0230
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]230 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation230 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 18.5879(6) Å · b = 9.3660(3) Å · c = 9.9622(7) Å
Cell angles
β = 96.916(7) °
Ratio a:b:c
1 : 0.504 : 0.536
Unit cell volume
1721.75 ų
Z
4
Morphology

Prismatic crystals; tightly intergrown radial aggregates

Type-locality form

Prismatic crystals to about 1 mm in length grouped in tightly intergrown radial aggregates to about 2 mm in diameter

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
40.07%
33AsArsenicArsenic474.922299.688
37.53%
20CaCalciumCalcium340.078120.234
15.05%
12MgMagnesiumMagnesium224.30548.610
6.09%
1HHydrogenHydrogen101.00810.080
1.26%
Total798.592100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn

Synonyms

  • Chongiet
  • IMA2015-039

In other languages

German
Chongit · IMA 2015-039

Classification

Strunz
10th ed.

8.00

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.0— unnamed intermediate level —Division
  • 8.00— unnamed intermediate level —Group
  • 8.00ChongiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter 26. Mineralogical Magazine, 79 (4) 941-947 doi:10.1180/minmag.2015.079.4.05DOI: 10.1180/minmag.2015.079.4.05
  2. 2016Kampf, Anthony R., Nash, Barbara P., Dini, Maurizio, Molina Donoso, Arturo A. (2016) Chongite, Ca3Mg2(AsO4)2(AsO3OH)2·4H2O, a new arsenate member of the hureaulite group from the Torrecillas mine, Iquique Province, Chile. Mineralogical Magazine, 80 (7) 1255-1263 doi:10.1180/minmag.2016.080.064 DOI: 10.1180/minmag.2016.080.064
  3. 2017(2017) Chongite. Handbook of Mineralogy. Mineralogical Society of America
