Miguelromeroite

Mn5(AsO3OH)2(AsO4)2(H2O)4
IMA status
  • Approved
IMA symbol
Mig
IMA approved
2009
Also known as
  • IMA2008-066
  • Miguelromeroiet

Where it forms, where it's found

Geological setting

Secondary oxidation zone assemblage.

Type locality
Ojuela Mine
  1. Mapimí
  2. Mapimí Municipality
  3. Durango
  4. Mexico

25.7936°, -103.7911°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Orange-pink · pink · pale pink · colourless
Streak
Very pale pink
Tenacity
brittle
Cleavage
Distinct/Good

on (100)

Fracture
Conchoidal
Density
3.69 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70° · 2V calc = 75°
Refractive index
1.713 – 1.729
Surface relief
High
Principal indices
nα 1.713 · nβ 1.723 · nγ 1.729
Pleochroism
Visible

Shades of pale pink.

Dispersion
None observed
Extinction
X = b, Z ∧ c = 40° in obtuse β.
Notes

Absorption: Z >> X > Y.

Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 18.0300(10) Å · b = 9.2715(5) Å · c = 9.7756(5) Å
Cell angles
β = 96.266(2) °
Ratio a:b:c
1 : 0.514 : 0.542
Morphology

Crystals are elongate on [001] and exhibit the forms (100), (110), and (101).

Twinning

None observed.

Type-locality form

A compact spray of orange-pink, prismatic crystals up to 4 cm in length (Ojuela mine). Transparent orange-pink crystals in flattened, circular, radial (7 mm diameter) aggregates (Stirling Hill). Sprays and divergent aggregates of transparent pink prisms to several millimeters in length (Veta Negra mine).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
35.38%
33AsArsenicArsenic474.922299.688
33.14%
25MnManganeseManganese554.938274.690
30.37%
1HHydrogenHydrogen101.00810.080
1.11%
Total904.438100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2008-066
  • Miguelromeroiet

In other languages

French
Miguelroméroïte
German
IMA 2008-066 · Miguelromeroit

Classification

Strunz
10th ed.

8.CB.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CBWith only medium-sized cations, RO4:H2O = 1:1Group
  • 8.CB.10MiguelromeroiteSpecies
Dana
8th ed.

39.02.01.04

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.02(AB)5[HXO4]2[XO4]2.xH2OType
  • 39.02.01Hureaulite GroupGroup
  • 39.02.01.04MiguelromeroiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2002Stock, N., Stucky, G. D., Cheetham, A. K. (2002) Synthesis and Characterization of the Synthetic Minerals Villyaellenite and Sarkinite, Mn5(AsO4)2(HAsO4)2 · 4H2O and Mn2(AsO4)(OH). Zeitschrift für anorganische und allgemeine Chemie, 628. 357-362 doi:10.1002/1521-3749(200202)628:2<357::aid-zaac357>3.0.co;2-vDOI: 10.1002/1521-3749(200202)628:2<357::aid-zaac357>3.0.co;2-v
  2. 2009Kampf, A. R. (2009) Miguelromeroite, the Mn analogue of sainfeldite, and redefinition of villyaellenite as an ordered intermediate in the sainfeldite-miguelromeroite series. American Mineralogist, 94 (11) 1535-1540 doi:10.2138/am.2009.3278DOI: 10.2138/am.2009.3278
  3. 2021(2021) Miguelromeroite. Handbook of Mineralogy. Mineralogical Society of America
