Oxy-chromium-dravite

NaCr3(Cr4Mg2)(Si6O18)(BO3)3(OH)3O
IMA status
  • Approved
IMA symbol
Ocdrv
IMA approved
2012
Also known as
  • IMA2011-097
  • Oxy-chromium-draviet
  • Oxy-Chromium-Dravit

Where it forms, where it's found

Geological setting

chromphyllite-bearing quartzite and banded quartz-diopside rock

Metaquartzites

Type locality
Pereval marble quarry
  1. Slyudyanka
  2. Russia

51.6201°, 103.6334°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Emerald green
Streak
Green
Fracture
Conchoidal
Density
3.299 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.715 – 1.765
Surface relief
High
Principal indices
nω 1.765 · nε 1.715
Pleochroism
Visible

pleochroic (O = dark green, E = yellow green) (in plane-polarized light)

Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R3m
Cell parameters
a = 16.1121(3) Å · c = 7.3701(1) Å
Unit cell volume
1656.95 ų
Z
3
Type-locality form

elongated prisms terminated by a prominent pedion and small, minor pyramidal faces

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
43.68%
24CrChromiumChromium751.996363.972
32.05%
14SiSiliconSilicon628.085168.510
14.84%
12MgMagnesiumMagnesium224.30548.610
4.28%
5BBoronBoron310.81032.430
2.86%
11NaSodiumSodium122.99022.990
2.02%
1HHydrogenHydrogen31.0083.024
0.27%
Total1135.505100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-097
  • Oxy-chromium-draviet
  • Oxy-Chromium-Dravit

In other languages

German
IMA 2011-097 · Oxy-Chrom-Dravit
Italian
oxy-chromium-dravite

Classification

Strunz
10th ed.

9.CK.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.05Oxy-chromium-draviteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 13. Mineralogical Magazine, 76 (3) 807-817 doi:10.1180/minmag.2012.076.3.26 DOI: 10.1180/minmag.2012.076.3.26
  2. 2012Bosi, F., Reznitskii, L., Skogby, H. (2012) Oxy-chromium-dravite, NaCr3(Cr4Mg2)(Si6O18)(BO3)3(OH)3O, a new mineral species of the tourmaline supergroup. American Mineralogist, 97 (11) 2024-2030 doi:10.2138/am.2012.4210 DOI: 10.2138/am.2012.4210
  3. 2014Vereshchagin, Oleg S., Rozhdestvenskaya, Ira V., Frank-Kamenetskaya, Olga V., Zolotarev, Anatoly A. (2014) Ion substitutions and structural adjustment in Cr-bearing tourmalines. European Journal of Mineralogy, 26 (2) 309-321 doi:10.1127/0935-1221/2014/0026-2372DOI: 10.1127/0935-1221/2014/0026-2372
  4. 2017(2017) Oxy-chromium-dravite. Handbook of Mineralogy. Mineralogical Society of America
