Collinsite

Ca2Mg(PO4)2 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Coll
Discovered
1924
Also known as
  • Collinsiet

Where it forms, where it's found

Geological setting

Vein deposit in andesite.

Type locality
Francois Lake phosphate occurrence
  1. Francois Lake
  2. Omineca Mining Division
  3. British Columbia
  4. Canada

54.0789°, -125.7564°

37recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Light brown · light yellow-brown to colourless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Imperfect/Fair

On (001) and (010), fair.

Density
2.99 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80°
Refractive index
1.632 – 1.657
Surface relief
Moderate
Principal indices
nα 1.632 · nβ 1.642 · nγ 1.657
Dispersion
r < v strong
Michel-Lévy diagramhighlighted lineδ = 0.0250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]250 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation250 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.73 Å · b = 6.78 Å · c = 5.44 Å
Cell angles
α = 97.29 ° · β = 108.56 ° · γ = 107.28 °
Ratio a:b:c
1 : 1.183 : 0.949
Morphology

Radial blades or lath-like fibers elongated [100], comprising layers.

Type-locality form

Layers in phosphate nodules, consisting of elongated blades to 1 cm in length by 0.5 mm in width.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
48.42%
20CaCalciumCalcium240.07880.156
24.26%
15PPhosphorusPhosphorus230.97461.948
18.75%
12MgMagnesiumMagnesium124.30524.305
7.35%
1HHydrogenHydrogen41.0084.032
1.22%
Total330.431100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Collinsiet

In other languages

French
collinsite
German
Collinsit
Spanish
collinsita
Italian
collinsite
Chinese
磷钙镁石

Classification

Strunz
10th ed.

8.CG.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.05CollinsiteSpecies
Dana
8th ed.

40.02.02.03

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.02AB2(XO4)2·xH2OType
  • 40.02.02Fairfieldite Subgroup (Triclinic: P-1¯)Group
  • 40.02.02.03CollinsiteSpecies
CIM

19.14.20

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.20CollinsiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1924POITEVIN, E. & CONNOR, M.F. (1924): Collinsite (hydrated phosphate of lime), a new mineral. Transactions of the Royal Society of Canada 18, XLII.
  2. 1926POITEVIN, E. (1926): A new Canadian occurrence of phosphorite from near Francois Lake, British Columbia. Geological Survey of Canada, Museum Bulletin 46, 1-21.
  3. 1927Poitevin, E. (1927) A new Canadian occurrence of phosphorite from near Francois Lake, British Columbia. Canada Department of Mines, Bulletin: 46: 2-12.
  4. 1928Foshag, W.F. (1928) New mineral names. American Mineralogist: 13: 201-202.
  5. 1940Wolfe, C. W. (1940) Classification of minerals of the type A3(XO4)2·nH2O. American Mineralogist, 25 (11) 738-753
