Gordonite

MgAl2(PO4)2(OH)2 · 8H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gdo
Discovered
1930
Also known as
  • Gordoniet

Where it forms, where it's found

Geological setting

Variscite nodules in limestone.

Complex granitic pegmatite

Type locality
Clay Canyon
  1. Fairfield
  2. Sunshine Mining District
  3. Utah County
  4. Utah
  5. USA

40.2764°, -112.1604°

24recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Smoky-white · buff · colourless · crystals = pale pink or pale green on tips · colourless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (010), perfect; on (100), fair; on (001), poor.

Fracture
Conchoidal
Density
2.23 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 73°
Refractive index
1.534 – 1.558
Surface relief
Moderate
Principal indices
nα 1.534 · nβ 1.543 · nγ 1.558
Dispersion
r > v weak
Extinction
X ≃ ⊥ {010}.
Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 5.246 Å · b = 10.532 Å · c = 6.975 Å
Cell angles
α = 107.51 ° · β = 111.03 ° · γ = 72.21 °
Ratio a:b:c
1 : 2.008 : 1.330
Z
1
Morphology

Crystals rare, prismatic [001] to platy (010), with dominant basal pedions; elongated and strongly striated along [001], and less markedly on [100]. (001) is lacking at times, leaving the crystals terinated entirely by (011); rarely doubly terinated. May exhibit numerous lesser forms. Commonly in bundles and sheaflike aggregates with all individual crystals of one group similarly terminated.

Type-locality form

Poor crystals, but giving some reflections from faces.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
64.52%
15PPhosphorusPhosphorus230.97461.948
13.88%
13AlAluminiumAluminium226.98253.964
12.09%
12MgMagnesiumMagnesium124.30524.305
5.45%
1HHydrogenHydrogen181.00818.144
4.06%
Total446.343100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gordoniet

In other languages

German
Gordonit
Italian
Gordonite
Chinese
磷镁铝石

Classification

Strunz
10th ed.

8.DC.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.30GordoniteSpecies
Dana
8th ed.

42.11.14.04

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.14Vauxite GroupGroup
  • 42.11.14.04GordoniteSpecies
CIM

19.8.9

  • 19PhosphatesClass
  • 19.8Phosphates of Al and other metalsGroup
  • 19.8.9GordoniteSpecies

Group, growth & confusion

Often grow together
4 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1930Larsen, Esper S., Shannon, Earl V. (1930) The minerals of the phosphate nodules from near Fairfield, Utah. American Mineralogist, 15 (8) 307-337
  2. 1937Pough, F. H. (1937) The morphology of gordonite. American Mineralogist, 22 (5) 625-629
  3. 1942Larsen, Esper S., 3d, (1942) The mineralogy and paragenesis of the variscite nodules from near Fairfield, Utah, Part 1. American Mineralogist, 27 (4) 281-300
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1962Hurlbut, Cornelius S., Honea, Russell (1962) Sigloite, a new mineral from Llallagua, Bolivia. American Mineralogist, 47 (1-2) 1-8
