Costibite

CoSbS
IMA status
  • Approved
IMA symbol
Csb
Discovered
1970
Also known as
  • Costibiet
  • IMA1969-014

Where it forms, where it's found

Geological setting

Hydrothermal veins

Type locality
Consols Mine (ABH Consols Mine
  1. Australian Broken Hill Consols Mine)
  2. Broken Hill
  3. Broken Hill district
  4. Yancowinna Co.
  5. New South Wales
  6. Australia

-31.9634°, 141.4823°

27recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Density
6.89 g/cm³

Optical

Pleochroism
Weak

Gray-white with bluish to brownish tints.

Optical colour
Grayish
Anisotropism
Weak, reddish brown or orange to bluish
Tropism
Anisotropic
Reflectance R%
(44.4) 470, (45.9) 546, (45.5) 589, (47.8) 650
Reflected-light panel
45.9 %isotropic · single curve
Specimen sRGB 241, 166, 91
White reference100 % reflector under same lamp
Anisotropism
Weak, reddish brown or orange to bluish
Reflected colour
Grayish

Crystallography

Crystal system
Orthorhombic
Space group
#34
Cell parameters
a = 3.603 Å · b = 4.868 Å · c = 5.838 Å
Ratio a:b:c
1 : 1.351 : 1.620
Z
2
Morphology

Lamellar inclusions in loellingite, intergrown with paracostibite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
57.23%
27CoCobaltCobalt158.93358.933
27.70%
16SSulfurSulfur132.06032.060
15.07%
Total212.753100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ni
  • As

Synonyms

  • Costibiet
  • IMA1969-014

In other languages

German
Costibit · IMA 1969-014
Italian
Costibite

Classification

Strunz
10th ed.

2.EB.10d

  • 2Sulfides and SulfosaltsClass
  • 2.EMetal Sulfides, M: S <= 1:2Division
  • 2.EBM:S = 1:2, with Fe, Co, Ni, PGE, etc.Group
  • 2.EB.10dCostibiteSpecies
Dana
8th ed.

02.12.07.01

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.07Costibite Group (Orthorhombic Cobalt Arsenides or Antimonides)Group
  • 02.12.07.01CostibiteSpecies
CIM

3.10.15

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.10Sulphides etc. of CoGroup
  • 3.10.15CostibiteSpecies

Group, growth & confusion

In the same group
11 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1970Cabri, L. J., Harris, D. C., Stewart, and J. M. (1970) Costibite (CoSbS) A new mineral from Broken Hill, N.S.W., Australia. American Mineralogist, 55 (1-2) 10-17
  2. 1975Rowland, J. F.; Gabe, E. J.; Hall, S. R. (1975) The crystal structures of costibite (CoSbS) and paracostibite (CoSbS). The Canadian Mineralogist, 13 (2). 188-196
  3. 1980Zakrzewski, M.A., Burke, E.A.J., Nugteren, H.W. (1980) Cobalt Minerals in the Hällefors area, Bergslagen, Sweden: New occurences of costibite, paracostibite, nisbite and cobaltian ullmannite. The Canadian Mineralogist, 18 (2) 165-171
  4. 2005(2005) Costibite. Handbook of Mineralogy. Mineralogical Society of America
