Nisbite

NiSb2
IMA status
  • Approved
IMA symbol
Nis
Discovered
1970
Also known as
  • IMA1969-017
  • Nisbiet

Where it forms, where it's found

Type locality
Trout Bay Copper Mine
  1. Mulcahy Township
  2. Kenora District
  3. Ontario
  4. Canada

51.0028°, -94.2094°

34recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Tin white
Density
8.0 g/cm³

Optical

Pleochroism
Weak
Optical colour
White
Anisotropism
weak
Bireflectance
very weak
Tropism
Anisotropic

Crystallography

Crystal system
Orthorhombic
Space group
Pnnm
Cell parameters
a = 5.17 Å · b = 6.31 Å · c = 3.83 Å
Ratio a:b:c
1 : 1.221 : 0.741
Z
2
Type-locality form

As irregular grains, to 20 µm

Comment

(synthetic)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony2121.760243.520
80.58%
28NiNickelNickel158.69358.693
19.42%
Total302.213100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1969-017
  • Nisbiet

In other languages

German
IMA 1969-017 · Nisbit
Italian
Nisbite

Classification

Strunz
10th ed.

2.EB.15a

  • 2Sulfides and SulfosaltsClass
  • 2.EMetal Sulfides, M: S <= 1:2Division
  • 2.EBM:S = 1:2, with Fe, Co, Ni, PGE, etc.Group
  • 2.EB.15aNisbiteSpecies
Dana
8th ed.

02.12.02.13

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.02Marcasite Group (Orthorhombic: Pnnm)Group
  • 02.12.02.13NisbiteSpecies

Group, growth & confusion

In the same group
11 members

Literature, links & citation

Citations
  1. 1970Cabri, L. J., Harris, D. C., Stewart, J. M. (1970) Paracostibite (CoSbS) and nisbite (NiSb2), new minerals from the Red Lake area, Ontario, Canada. The Canadian Mineralogist, 10 (2) 232-246
  2. 1971Fleischer, Michael (1971) New Mineral Names. American Mineralogist, 56 (3-4) 631-640
  3. 1974Kjekshus, Arne, Rakke, Trond, Andresen, Arne F., Southern, J. T. (1974) Compounds with the Marcasite Type Crystal Structure. IX. Structural Data for FeAs2, FeSe2, NiAs2, NiSb2, and CuSe2. Acta Chemica Scandinavica, 28. 996-1000 doi:10.3891/acta.chem.scand.28a-0996DOI: 10.3891/acta.chem.scand.28a-0996
  4. 1979Kjekshus, Arne; Peterzéns, Per G.; Rakke, Trond; Andresen, Arne F.; Hoyer, Eberhard; Spiridonov, V. P.; Strand, T. G. (1979) Compounds with the marcasite type crystal structure. XIII. Structural and magnetic properties of CrtFe1-tAs2, CrtFe1-tSb2, Fe1-tNitAs2 and Fe1-t NitSb2. Acta Chemica Scandinavica, A33. 469-480 doi:10.3891/acta.chem.scand.33a-0469DOI: 10.3891/acta.chem.scand.33a-0469
  5. 1980Zakrzewski, M.A., Burke, E.A.J., Nugteren, H.W. (1980) Cobalt Minerals in the Hällefors area, Bergslagen, Sweden: New occurences of costibite, paracostibite, nisbite and cobaltian ullmannite. The Canadian Mineralogist, 18 (2) 165-171
