Alloclasite

CoAsS
IMA status
  • Approved
  • Grandfathered
IMA symbol
Acl
Discovered
1866
Also known as
  • Alloclase
  • Alloclasiet
  • Alloclasit
  • +2 more

Where it forms, where it's found

Geological setting

In calcite or quartz veins of apparently low-temperature, late-stage hydrothermal origin. Also in silicified, recrystallized metamorphic rock.

Type locality
Elizabeth Mine
  1. Oraviţa
  2. Caraş-Severin County
  3. Romania
86recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Steel gray to silver
Streak
Nearly black
Tenacity
brittle
Cleavage
Perfect

perfect on (101) distinct on (010)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
5.95 g/cm³

Optical

Tropism
Anisotropic
Reflectance R%
(49.5, 48.2) 400, (48.7, 48.3) 420, (48.2, 48.6) 440, (47.8, 48.8) 460, (47.6, 49.2) 480, (47.6, 49.7) 500, (47.8, 50.1) 520, (48.0, 50.4) 540, (48.1, 50.5) 560, (48.4, 50.6) 580, (48.6, 50.7) 600, (48.8, 50.7) 620, (49.0, 50.5) 640, (49.1, 50.3) 660, (49.1, 50.1) 680, (49.2, 49.9) 700
Reflected-light panel
48.5 %anisotropic · dual curve
Specimen sRGB 246, 170, 95
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Monoclinic
Space group
#9
Cell parameters
a = 4.661 Å · b = 5.602 Å · c = 3.411 Å
Cell angles
β = 90.03 °
Ratio a:b:c
1 : 1.202 : 0.732
Z
2
Morphology

Crystals are prismatic parallel [010] , to 5 mm, in columnar to radiating aggregates; commonly massive.

Type-locality form

Steel gray and fissile.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
33AsArsenicArsenic174.92274.922
45.16%
27CoCobaltCobalt158.93358.933
35.52%
16SSulfurSulfur132.06032.060
19.32%
Total165.915100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ni

Synonyms

  • Alloclase
  • Alloclasiet
  • Alloclasit
  • Alloclasita
  • Alloklasitt

In other languages

French
Alloclasite
German
Alloklas
Italian
alloclasite

Classification

Strunz
10th ed.

2.EB.10b

  • 2Sulfides and SulfosaltsClass
  • 2.EMetal Sulfides, M: S <= 1:2Division
  • 2.EBM:S = 1:2, with Fe, Co, Ni, PGE, etc.Group
  • 2.EB.10bAlloclasiteSpecies
Dana
8th ed.

02.12.06.02

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.06— unnamed intermediate level —Group
  • 02.12.06.02AlloclasiteSpecies
CIM

3.10.16

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.10Sulphides etc. of CoGroup
  • 3.10.16AlloclasiteSpecies

Group, growth & confusion

In the same group
11 members
Often grow together
9 minerals

Literature, links & citation

Citations
  1. 1866Tschermak, G. (1866) Der alloklas und der sogenannte glaukodot von Orawicza. Sitzungsberichte der Kaiserlichen Akademie der Wissenschaften, 53, 220-225.
  2. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  3. 1971Kingston, P.W. (1971) Alloclasite, cobalt-iron sulpharsenide. The Canadian Mineralogist: 10: 838-846.
  4. 1971Petruk, W., Harris, D.C., Stewart, J.M. (1971) The silver-arsenide deposits of the Cobalt-Gowganda region, Ontario. Canadian Mineralogist, 11(1), 150-186.
  5. 1973Maurel, Colette, Picot, Paul (1973) Sur le mécanisme de la transformation de l'alloclasite en cobaltite : cas du gisement du Lautaret. Bulletin de Minéralogie, 96 (4) 292-297 doi:10.3406/bulmi.1973.6831DOI: 10.3406/bulmi.1973.6831
