Delindeite

Ba2Ti2(Na2◻)Ti(Si2O7)2(OH)2(H2O)2O2
IMA status
  • Approved
IMA symbol
Dde
Discovered
1987
Also known as
  • Delindeiet
  • IMA1987-004

Where it forms, where it's found

Geological setting

In miarolitic cavities in nepheline syenite.

Type locality
Diamond Jo Quarry
  1. Magnet Cove
  2. Hot Spring County
  3. Arkansas
  4. USA

34.4382°, -92.8632°

5recorded occurrences
Source · OpenStreetMap

Physical

Lustre
Resinous to Pearly
Transparency
Translucent
Colour
Light pinkish-grey
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

[001] Good

Fracture
Irregular/Uneven
Density
3.3 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 54° · 2V calc = 54°
Refractive index
1.79 – 1.982
Surface relief
Very high
Principal indices
nα 1.79 · nβ 1.825 · nγ 1.982
Pleochroism
Non-pleochroic
Dispersion
single
Michel-Lévy diagramhighlighted lineδ = 0.1920
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1920 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1920 nm
Order4th order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 21.61 Å · b = 6.81 Å · c = 5.38 Å
Cell angles
β = 94.03 °
Ratio a:b:c
1 : 0.315 : 0.249
Z
1
Morphology

Lath-shaped crystals or flakes, forming compact spherulitic aggregates, to 1 mm.

Twinning

Submicroscopic on (100), common.

Type-locality form

Tiny, compact, spherulitic aggregates ranging up to about 1 mm in diameter.

Crystal structure

Chemical composition

Impurities
  • Mg

Synonyms

  • Delindeiet
  • IMA1987-004

In other languages

German
Delindeit · IMA 1987-004
Italian
Delindeite
Portuguese
Delindeíta · IMA1987-004

Classification

Strunz
10th ed.

9.BE.60

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.60DelindeiteSpecies
Dana
8th ed.

56.02.6c.02

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.6c— unnamed intermediate level —Group
  • 56.02.6c.02DelindeiteSpecies
CIM

14.9.19

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.19DelindeiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1987Appleman, Daniel E., Evans, Howard T., Nord, Gordon L., Dwornik, Edward J., Milton, Charles (1987) Delindeite titanosilicates and lourenswalsite, two new from the Magnet Cove region, Arkansas. Mineralogical Magazine, 51 (361) 417-425 doi:10.1180/minmag.1987.051.361.08 DOI: 10.1180/minmag.1987.051.361.08
  2. 1988Jambor, John L., Ercit, Ernst A. J. Burke T. Scott, Grice, Joel D. (1988) New Mineral Names. American Mineralogist, 73 (11-12) 1492-1499
  3. 2001(2001) Delindeite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2001Ferraris, G., Ivaldi, G., Pushcharovsky, D. Yu., Zubkova, N. V., Pekov, I. V. (2001) The crystal structure of delindeite, Ba2{(Na,K,◻) 3(Ti,Fe)[Ti2(O,OH)4Si4O14](H2O,OH)2}, a member of the mero-plesiotype bafertisite series. The Canadian Mineralogist, 39 (5) 1307-1316 doi:10.2113/gscanmin.39.5.1307 DOI: 10.2113/gscanmin.39.5.1307
  5. 2002Jambor, J.L., Roberts, A.C. (2002) New mineral names. American Mineralogist: 87: 996-999.
