Esseneite

CaFe3+AlSiO6
IMA status
  • Approved
IMA symbol
Ess
Discovered
1987

Where it forms, where it's found

Geological setting

A fusion product of sediments overlying and associated with naturally combusted coal seam.

Type locality
Durham Ranch paralava occurrence
  1. Reno Junction
  2. Campbell County
  3. Wyoming
  4. USA
22recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Red-brown
Streak
White
Cleavage
Perfect
Density
3.54 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 77° · 2V calc = 68°
Refractive index
1.795 – 1.825
Surface relief
Very high
Principal indices
nα 1.795 · nβ 1.815 · nγ 1.825
Pleochroism
Visible

X = lemon yellow; Y = greenish yellow; and Z = apple-green.

Dispersion
r << v
Extinction
Y = b; Z ∧ c = 9°+/-3° in the acute angle β.
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 9.79(1) Å · b = 8.822(9) Å · c = 5.37(1) Å
Cell angles
β = 105.81(9) °
Ratio a:b:c
1 : 0.901 : 0.549
Morphology

Prismatic crystals.

Type-locality form

Prismatic crystals 2-8 mm in length.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
38.87%
26FeIronIron155.84555.845
22.61%
20CaCalciumCalcium140.07840.078
16.23%
14SiSiliconSilicon128.08528.085
11.37%
13AlAluminiumAluminium126.98226.982
10.92%
Total246.984100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mn
  • Mg
  • Na

In other languages

German
Esseneit · IMA 1985-048
Italian
Esseneite
Chinese
紅鋁透輝石 · 铁钙铝辉石

Classification

Strunz
10th ed.

9.DA.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DAInosilicates with 2-periodic single chains, Si2O6; pyroxene familyGroup
  • 9.DA.15EsseneiteSpecies
Dana
8th ed.

65.01.3a.06

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
  • 65.01.3a— unnamed intermediate level —Group
  • 65.01.3a.06EsseneiteSpecies
CIM

16.21.1

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.21Aluminosilicates of Fe and CaGroup
  • 16.21.1EsseneiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1969Clark, J.R., Appleman, D.E., Papike, J.J. (1969) Crystal-chemical characterization of clinopyroxenes based on eight new structure refinements. MSA Special Paper: 2: 31-50.
  2. 1987Cosca, Michael A., Peacor, Donald R. (1987) Chemistry and structure of esseneite (CaFe2+AlSiO6), a new pyroxene produced by pyrometamorphism. American Mineralogist, 72 (1-2) 148-156
  3. 1988Morimoto, N., Fabries, J., Ferguson, A. K., Ginzburg, I. V., Ross, M., Seifert, F. A., Zussman, J., Aoki, K., Gottardi, G. (1988) Nomenclature of Pyroxenes. Mineralogical Magazine, 52 (367) 535-550 doi:10.1180/minmag.1988.052.367.15DOI: 10.1180/minmag.1988.052.367.15
  4. 2001(2001) Esseneite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2016Nespolo, Massimo, Aroyo, Mois I (2016) The modular structure of pyroxenes. European Journal of Mineralogy, 28 (1) 189-203 doi:10.1127/ejm/2015/0027-2492DOI: 10.1127/ejm/2015/0027-2492
