Fluorvesuvianite

Ca19(Al,Mg)13(SiO4)10(Si2O7)4O(F,OH)9
IMA status
  • Approved
IMA symbol
Fves
IMA approved
2000
Also known as
  • Fluorvesuvian
  • Fluorvesuvianiet

Where it forms, where it's found

Geological setting

calcite filled vugs of a diopside-magnetite skarn

Type locality
Lupikko Mine
  1. Pitkyaranta mining district
  2. Pitkyarantsky District
  3. Republic of Karelia
  4. Russia

61.5500°, 31.5000°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colourless to white
Streak
white
Tenacity
brittle
Cleavage
None Observed
Density
3.43 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.699 – 1.702
Surface relief
High
Principal indices
nω 1.702 · nε 1.699 · n 1.7
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0030
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]30 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation30 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P4/nnc
Cell parameters
a = 15.51 Å · c = 11.77 Å
Z
2
Morphology

(100), (110), elongated along [001]

Type-locality form

fibrous crystals to 1.5 cm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen7815.9991247.922
37.12%
20CaCalciumCalcium1940.078761.482
22.65%
14SiSiliconSilicon1828.085505.530
15.04%
13AlAluminiumAluminium1326.982350.766
10.43%
12MgMagnesiumMagnesium1324.305315.965
9.40%
9FFluorineFluorine918.998170.982
5.09%
1HHydrogenHydrogen91.0089.072
0.27%
Total3361.719100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluorvesuvian
  • Fluorvesuvianiet

In other languages

German
Fluorvesuvianit · IMA 2000-037
Italian
Fluorvesuvianite

Classification

Strunz
10th ed.

9.BG.35

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.35FluorvesuvianiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 2003Britvin, S. N.; Antonov, A. A.; Krivovichev, S. V.; Armbruster, T.; Burns, P. C.; Chukanov, N. V. (2003) Fluorvesuvianite, Ca19(Al,Mg,Fe2+)13[SiO4]10[Si2O7]4O(F,OH)9, a new mineral species from Pitkaranta, Karelia, Russia: Description and crystal structure. The Canadian Mineralogist, 41 (6). 1371-1380 doi:10.2113/gscanmin.41.6.1371 DOI: 10.2113/gscanmin.41.6.1371
  2. 2004Lapis (2004): 29(3):40.
  3. 2021(2021) Fluorvesuvianite. Handbook of Mineralogy. Mineralogical Society of America
